50
HCD-EC69/EC79/EC99
SECTION 8
ELECTRICAL PARTS LIST
2CH-4CH AMP BOARD
******************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C107 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C108 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C109 1-126-947-11 ELECT 47uF 20% 35V
C110 1-126-947-11 ELECT 47uF 20% 35V
C111 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C112 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EC79)
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EC79)
C121 1-126-960-11 ELECT 1uF 20% 50V
(EC79)
C122 1-126-960-11 ELECT 1uF 20% 50V
(EC79)
C123 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(EC79)
C124 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
(EC79)
C125 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(EC79)
C126 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(EC79)
C127 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(EC79)
C128 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
(EC79)
C129 1-126-960-11 ELECT 1uF 20% 50V
(EC79)
C130 1-126-960-11 ELECT 1uF 20% 50V
(EC79)
C141 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C142 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C151 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79)
C152 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79)
C160 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C161 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C162 1-126-968-11 ELECT 100uF 20% 50V
(EC69/EC99)
C162 1-126-969-11 ELECT 220uF 20% 50V
(EC79)
C163 1-126-968-11 ELECT 100uF 20% 50V
(EC69/EC99)
C163 1-126-969-11 ELECT 220uF 20% 50V
(EC79)
C164 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C165 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C166 1-126-964-11 ELECT 10uF 20% 50V
(EC79)
C167 1-126-964-11 ELECT 10uF 20% 50V
(EC79)
< CONNECTOR >
CN100 1-784-766-11 CONNECTOR, FFC 5P
CN101 1-820-831-11 HOLDER, CABLE 7P (EC79)
CN102 1-824-030-21 HOLDER, CABLE 5P (EC69/EC99)
< DIODE >
D140 6-501-817-01 DIODE MA2J1110GLS0
D141 6-500-335-01 DIODE MC2838-T112-1
D152 6-500-335-01 DIODE MC2838-T112-1 (EC79)
< IC >
IC101 6-600-731-01 IC STK433-870-E (EC79)
IC102 6-705-620-01
IC STK433-060 (EC69)
IC102 6-705-621-01 IC STK433-070 (EC99)
< JUMPER RESISTOR >
JR101 1-216-864-11
SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q141 6-551-270-01 TRANSISTOR 2SA2026
Q142 6-551-270-01 TRANSISTOR 2SA2026
Q151 6-551-270-01 TRANSISTOR 2SA2026 (EC79)
Q152 6-551-270-01 TRANSISTOR 2SA2026 (EC79)
< RESISTOR >
R103 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EC79)
R103 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EC99)
R103 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(EC69: E2, E51, MX, AR)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
2CH-4CH AMP
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
• Abbreviation
AR : Argentina model
E2 : 120V AC area in E model
E51 : Chilean and Peruvian models
MX : Mexican model
RU : Russian model
Ver. 1.1
