Sony HCD-EC79 - 3 CH AMP Board Parts List

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69/EC79/EC99
5151
R103 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC69: AEP, RU)
R104 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EC79)
R104 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EC99)
R104 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(EC69: E2, E51, MX, AR)
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC69: AEP, RU)
R105 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC69)
R105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC79/EC99)
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC69)
R106 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC79/EC99)
R107 1-216-841-11 METAL CHIP 47K 5% 1/10W
R108 1-216-841-11 METAL CHIP 47K 5% 1/10W
R109 1-216-817-11 METAL CHIP 470 5% 1/10W
R110 1-216-817-11 METAL CHIP 470 5% 1/10W
0 R111 1-216-361-31 METAL OXIDE 0.22 5% 2W F
0 R112 1-216-361-31 METAL OXIDE 0.22 5% 2W F
R113 1-216-841-11 METAL CHIP 47K 5% 1/10W
R114 1-216-841-11 METAL CHIP 47K 5% 1/10W
R115 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R116 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R119 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-821-11 METAL CHIP 1K 5% 1/10W
R123 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EC79)
R124 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EC79)
R125 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC79)
R126 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC79)
R127 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC79)
R128 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC79)
R129 1-216-817-11 METAL CHIP 470 5% 1/10W
(EC79)
R130 1-216-817-11 METAL CHIP 470 5% 1/10W
(EC79)
0 R131 1-216-361-31 METAL OXIDE 0.22 5% 2W F
(EC79)
0 R132 1-216-361-31 METAL OXIDE 0.22 5% 2W F
(EC79)
R133 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC79)
R134 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC79)
R135 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EC79)
R136 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EC79)
R141 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R142 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R143 1-216-837-11 METAL CHIP 22K 5% 1/10W
R144 1-216-837-11 METAL CHIP 22K 5% 1/10W
R145 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R146 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
3CH AMP
R151 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EC79)
R152 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
(EC79)
R153 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EC79)
R154 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EC79)
R155 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC79)
R156 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC79)
R160 1-216-813-11 METAL CHIP 220 5% 1/10W
R161 1-216-813-11 METAL CHIP 220 5% 1/10W
R162 1-216-813-11 METAL CHIP 220 5% 1/10W
R163 1-216-813-11 METAL CHIP 220 5% 1/10W
R164 1-216-813-11 METAL CHIP 220 5% 1/10W
(EC79)
R165 1-216-813-11 METAL CHIP 220 5% 1/10W
(EC79)
R166 1-216-813-11 METAL CHIP 220 5% 1/10W
(EC79)
R167 1-216-813-11 METAL CHIP 220 5% 1/10W
(EC79)
************************************************************
3CH AMP BOARD (EC99)
**************
< CAPACITOR >
C201 1-126-960-11 ELECT 1uF 20% 50V
C202 1-126-960-11 ELECT 1uF 20% 50V
C203 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C204 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C205 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C206 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C207 1-126-960-11 ELECT 1uF 20% 50V
C208 1-126-960-11 ELECT 1uF 20% 50V
C209 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C210 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C211 1-126-960-11 ELECT 1uF 20% 50V
C212 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C213 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C214 1-126-947-11 ELECT 47uF 20% 35V
C215 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C216 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C217 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C218 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C219 1-126-968-11 ELECT 100uF 20% 50V
C220 1-126-968-11 ELECT 100uF 20% 50V
C223 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C224 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C225 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C226 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C227 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C228 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C229 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C230 1-165-621-91 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN203 1-568-826-11 CONNECTOR, FFC 7P
CN205 1-820-831-11 HOLDER, CABLE 7P
2CH-4CH AMP
Ver. 1.2
