Sony HCD-EC79 - PANEL, PT-SWITCH, and REG Board Parts List

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69/EC79/EC99
54
< RESISTOR >
R404 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R405 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R406 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R407 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R408 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R409 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R410 1-216-835-11 METAL CHIP 15K 5% 1/10W
R411 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
SW311 1-771-410-21 SWITCH, TACTILE (x)
SW321 1-771-410-21 SWITCH, TACTILE (CD)
SW322 1-771-410-21 SWITCH, TACTILE (USB)
SW323 1-771-410-21 SWITCH, TACTILE (FOLDER +)
SW324 1-771-410-21 SWITCH, TACTILE (TUNING +, M, L)
SW325 1-771-410-21 SWITCH, TACTILE (DSGX)
SW326 1-771-410-21 SWITCH, TACTILE (DISC 1)
SW327 1-771-410-21 SWITCH, TACTILE (DISC 2)
SW328 1-771-410-21 SWITCH, TACTILE (DISC 3)
SW329 1-771-410-21 SWITCH, TACTILE (Z)
************************************************************
A-1599-413-A MAIN BOARD, COMPLETE (EC99: AEP, RU)
A-1599-449-A MAIN BOARD, COMPLETE (EC79: AEP)
A-1599-465-A MAIN BOARD, COMPLETE (EC69: AEP, RU)
A-1702-676-A MAIN BOARD, COMPLETE (EC69: E2, E51, AR)
A-1706-659-A MAIN BOARD, COMPLETE (EC99: E2, E51, AR)
A-1706-661-A MAIN BOARD, COMPLETE (EC79: E2, E51, AR)
A-1718-681-A MAIN BOARD, COMPLETE (EC99: MX)
A-1718-683-A MAIN BOARD, COMPLETE (EC79: MX)
A-1718-685-A MAIN BOARD, COMPLETE (EC69: MX)
*********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S (EC99)
< CAPACITOR >
C601 1-126-962-11 ELECT 3.3uF 20% 50V
C602 1-126-947-11 ELECT 47uF 20% 35V
C603 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC79/EC99)
C604 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79/EC99)
C605 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79/EC99)
C606 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC79/EC99)
C607 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C608 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C609 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C610 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C611 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C612 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C613 1-126-964-11 ELECT 10uF 20% 50V
C614 1-126-963-11 ELECT 4.7uF 20% 50V
C615 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79/EC99)
C616 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC79/EC99)
C617 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C618 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C619 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C620 1-104-658-91 ELECT 100uF 20% 10V
C621 1-130-777-00 MYLAR 0.1uF 100V
(EC79/EC99)
C621 1-136-165-00 FILM 0.1uF 5% 50V
(EC69)
C622 1-126-974-11 ELECT 3300uF 20% 50V
(EC79: AEP/EC99: AEP, RU)
C622 1-128-550-11 ELECT 2200uF 20% 50V
(EC69)
C623 1-130-777-00 MYLAR 0.1uF 100V
(EC79/EC99)
C623 1-136-165-00 FILM 0.1uF 5% 50V
(EC69)
C626 1-126-974-11 ELECT 3300uF 20% 50V
(EC79: AEP/EC99: AEP, RU)
C626 1-128-550-11 ELECT 2200uF 20% 50V
(EC69)
C627 1-126-943-11 ELECT 2200uF 20% 25V
C628 1-126-942-61 ELECT 1000uF 20% 25V
C629 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C630 1-126-947-11 ELECT 47uF 20% 35V
C631 1-126-933-11 ELECT 100uF 20% 16V
C632 1-126-963-11 ELECT 4.7uF 20% 50V
C633 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C634 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C636 1-126-960-11 ELECT 1uF 20% 50V
C637 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C638 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C639 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C640 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C641 1-126-962-11 ELECT 3.3uF 20% 50V
C642 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C644 1-126-960-11 ELECT 1uF 20% 50V
C645 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C646 1-126-960-11 ELECT 1uF 20% 50V
C647 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C648 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C649 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C650 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C652 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C654 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C655 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C656 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C657 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C658 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C661 1-126-964-11 ELECT 10uF 20% 50V
C662 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C663 1-126-960-11 ELECT 1uF 20% 50V
C664 1-126-960-11 ELECT 1uF 20% 50V
C665 1-126-960-11 ELECT 1uF 20% 50V
C666 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C667 1-126-933-11 ELECT 100uF 20% 16V
C669 1-126-923-91 ELECT 220uF 20% 10V
C671 1-126-933-11 ELECT 100uF 20% 16V
C674 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C675 1-126-960-11 ELECT 1uF 20% 50V
C676 1-126-960-11 ELECT 1uF 20% 50V
C677 1-119-940-51 ELECT 4700uF 20% 50V
(EC79: E2, E51, MX, AR/EC99: E2, E51, MX, AR)
C678 1-119-940-51 ELECT 4700uF 20% 50V
(EC79: E2, E51, MX, AR/EC99: E2, E51, MX, AR)
KEY MAIN
Ver. 1.2
