Sony HCD-EC79 - MAIN Board Parts List (Part 1)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69/EC79/EC99
56
CN654 1-819-138-11 PIN, CONNECTOR 10P (EC99)
* CN801 1-506-680-11 PLUG, CONNECTOR (2.5mm) 3P
(ANTENNA FM/AM)
< DIODE >
D601 6-500-335-01 DIODE MC2838-T112-1
D602 6-500-335-01 DIODE MC2838-T112-1
D603 6-501-817-01 DIODE MA2J1110GLS0 (EC79/EC99)
D604 6-501-817-01 DIODE MA2J1110GLS0
D605 6-501-817-01 DIODE MA2J1110GLS0
D606 6-500-334-01 DIODE MC2836-T112-1
D607 6-502-619-01 DIODE 1N5402-C532-2 (EC69/EC79)
D608 6-502-619-01 DIODE 1N5402-C532-2 (EC69/EC79)
D609 6-502-619-01 DIODE 1N5402-C532-2 (EC69/EC79)
D610 6-502-619-01 DIODE 1N5402-C532-2 (EC69/EC79)
D611 6-501-582-01 DIODE 1N4002-A2
D612 6-501-582-01 DIODE 1N4002-A2
D613 6-500-360-01 DIODE D10XB20 (EC99)
D614 6-501-817-01 DIODE MA2J1110GLS0
D615 6-501-582-01 DIODE 1N4002-A2
D617 6-500-335-01 DIODE MC2838-T112-1
D618 6-501-719-01 DIODE MAZ8039GHLS0
D619 6-501-582-01 DIODE 1N4002-A2
D620 6-501-582-01 DIODE 1N4002-A2
D621 6-501-722-01 DIODE MAZ8043GMLS0
D622 6-501-760-01 DIODE MAZ8100GMLS0
D627 8-719-062-51 DIODE 1PS226-115
D628 6-501-817-01 DIODE MA2J1110GLS0
D629 6-501-582-01 DIODE 1N4002-A2 (EC79/EC99)
D630 6-501-582-01 DIODE 1N4002-A2 (EC79/EC99)
D631 6-501-817-01 DIODE MA2J1110GLS0
D701 6-502-161-01 DIODE RB055L-40TE25
D702 6-501-817-01 DIODE MA2J1110GLS0 (EC99)
D791 6-501-817-01 DIODE MA2J1110GLS0
D801 6-502-623-01 DIODE SVC389
D802 8-719-062-51 DIODE 1PS226-115
D803 6-501-369-01 DIODE SVC230-TB-E
D804 6-501-369-01 DIODE SVC230-TB-E
D805 8-719-062-51 DIODE 1PS226-115
D806 8-719-062-51 DIODE 1PS226-115
< FILTER >
FL801 1-760-393-11 FILTER, CERAMIC
FL803 1-236-711-21 FILTER, BAND PASS
< IC >
IC602 6-712-055-01 IC BD3499FV-E2
IC701 6-600-1
13-01 IC NJM2368V (TE2)
IC801 6-708-840-01 IC LV23003VA
< JUMPER RESISTOR >
JR600 1-216-864-1
1 SHORT CHIP 0 (EC99)
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR607 1-216-864-11 SHORT CHIP 0
JR608 1-216-864-11 SHORT CHIP 0
JR609 1-216-864-11 SHORT CHIP 0
JR610 1-216-864-11 SHORT CHIP 0
JR611 1-216-864-11 SHORT CHIP 0
JR612 1-216-864-11 SHORT CHIP 0
JR613 1-216-864-11 SHORT CHIP 0
JR614 1-216-864-11 SHORT CHIP 0
JR615 1-216-864-11 SHORT CHIP 0
JR616 1-216-864-11 SHORT CHIP 0
JR617 1-216-864-11 SHORT CHIP 0
JR618 1-216-864-11 SHORT CHIP 0
JR619 1-216-864-11 SHORT CHIP 0
JR620 1-216-864-11 SHORT CHIP 0
JR621 1-216-864-11 SHORT CHIP 0
< COIL >
L601 1-456-107-11 COIL, AIR-CORE (EC79/EC99)
L602 1-456-107-11 COIL, AIR-CORE (EC79/EC99)
L603 1-456-107-11 COIL, AIR-CORE
L604 1-456-107-11 COIL, AIR-CORE
L605 1-410-509-11 INDUCTOR 10uH
L701 1-456-467-11 INDUCTOR 100uH
L702 1-456-107-11 COIL, AIR-CORE (EC99)
L802 1-457-168-11 COIL, DET
L803 1-457-162-22 COIL, AIR-CORE
L804 1-457-163-22 COIL, AIR-CORE
L805 1-457-161-11 COIL, AM ANTENNA
L806 1-410-522-11 INDUCTOR 120uH
< TRANSISTOR >
Q601 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q602 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q603 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q604 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q605 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q606 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q608 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q610 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC99)
Q611 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q612 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q613 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF (EC99)
Q614 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF (EC99)
Q618 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q619 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q622 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q624 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q701 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC99)
Q702 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC99)
Q703 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC99)
Q704 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC99)
Q705 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC99)
Q706 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q707 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q708 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q709 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q710 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q804 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC99)
< RESISTOR >
R601 1-216-817-11 METAL CHIP 470 5% 1/10W
MAIN
