Sony HCD-EC79 - PANEL Board Parts List (Part 2)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69/EC79/EC99
60
C330 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C336 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C338 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C340 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C343 1-126-965-91 ELECT 22uF 20% 50V
C344 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C345 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C346 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C354 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C355 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C359 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C360 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN302 1-784-735-11 CONNECTOR, FFC 13P
CN303 1-824-027-21 HOLDER, CABLE 3P
CN306 1-784-751-11 CONNECTOR, FFC 29P
< DIODE >
D301 6-501-722-01 DIODE MAZ8043GMLS0
D302 6-501-817-01 DIODE MA2J1110GLS0
D303 6-500-334-01 DIODE MC2836-T112-1
D304 6-501-817-01 DIODE MA2J1110GLS0
D305 6-501-817-01 DIODE MA2J1110GLS0
D306 6-501-479-01 LED 1L0341Y23E0CA602 (STANDBY) (EC69)
D306 6-502-773-01 LED SELG2WA10C LF62 (STANDBY)
(EC79/EC99)
< IC >
IC301 A-1711-702-A IC MB90F830PF-GE1 (for SERVICE)
IC302 6-600-349-21 IC NJL23H400A
< LIQUID CRYSTAL DISPLAY >
LCD301 1-802-840-11 DISPLAY PANEL, LIQUID CRYSTAL (EC69)
LCD301 1-802-841-12 DISPLAY PANEL, LIQUID CRYSTAL (EC79/EC99)
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-037-13 TRANSISTOR KTA1271Y
Q303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q307 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q308 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q309 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q310 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q311 6-552-137-01 TRANSISTOR 2SA2166-T112-1W
Q312 6-552-137-01 TRANSISTOR 2SA2166-T112-1W
Q313 6-552-137-01 TRANSISTOR 2SA2166-T112-1W
Q314 6-552-137-01 TRANSISTOR 2SA2166-T112-1W
Q315 6-552-138-01 TRANSISTOR 2SC6053-T112-1F
Q316 6-552-138-01 TRANSISTOR 2SC6053-T112-1F
Q317 6-552-138-01 TRANSISTOR 2SC6053-T112-1F
Q318 6-552-138-01 TRANSISTOR 2SC6053-T112-1F
< RESISTOR >
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
R304 1-216-809-11 METAL CHIP 100 5% 1/10W
R305 1-216-809-11 METAL CHIP 100 5% 1/10W
R306 1-216-809-11 METAL CHIP 100 5% 1/10W
R307 1-216-809-11 METAL CHIP 100 5% 1/10W
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
R309 1-216-809-11 METAL CHIP 100 5% 1/10W
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
R311 1-216-809-11 METAL CHIP 100 5% 1/10W
R312 1-216-809-11 METAL CHIP 100 5% 1/10W
R313 1-216-809-11 METAL CHIP 100 5% 1/10W
R314 1-216-809-11 METAL CHIP 100 5% 1/10W
R315 1-216-809-11 METAL CHIP 100 5% 1/10W
R316 1-216-809-11 METAL CHIP 100 5% 1/10W
R317 1-216-809-11 METAL CHIP 100 5% 1/10W
R318 1-216-809-11 METAL CHIP 100 5% 1/10W
R319 1-216-809-11 METAL CHIP 100 5% 1/10W
R320 1-216-809-11 METAL CHIP 100 5% 1/10W
R321 1-216-809-11 METAL CHIP 100 5% 1/10W
R322 1-216-809-11 METAL CHIP 100 5% 1/10W
R323 1-216-809-11 METAL CHIP 100 5% 1/10W
R324 1-216-809-11 METAL CHIP 100 5% 1/10W
R325 1-216-797-11 METAL CHIP 10 5% 1/10W
R326 1-216-809-11 METAL CHIP 100 5% 1/10W
R327 1-216-809-11 METAL CHIP 100 5% 1/10W
R328 1-216-833-11 METAL CHIP 10K 5% 1/10W
R329 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R330 1-216-819-11 METAL CHIP 680 5% 1/10W
R331 1-216-845-11 METAL CHIP 100K 5% 1/10W
R332 1-216-833-11 METAL CHIP 10K 5% 1/10W
R333 1-216-845-11 METAL CHIP 100K 5% 1/10W
R334 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R335 1-216-837-11 METAL CHIP 22K 5% 1/10W
R336 1-216-833-11 METAL CHIP 10K 5% 1/10W
R337 1-216-813-11 METAL CHIP 220 5% 1/10W
R338 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R339 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R340 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R341 1-216-839-11 METAL CHIP 33K 5% 1/10W
R342 1-216-849-11 METAL CHIP 220K 5% 1/10W
R343 1-216-853-11 METAL CHIP 470K 5% 1/10W
R344 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R345 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R346 1-216-841-11 METAL CHIP 47K 5% 1/10W
R347 1-216-817-11 METAL CHIP 470 5% 1/10W
R348 1-216-841-11 METAL CHIP 47K 5% 1/10W
R349 1-216-817-11 METAL CHIP 470 5% 1/10W
R350 1-216-841-11 METAL CHIP 47K 5% 1/10W
R351 1-216-817-11 METAL CHIP 470 5% 1/10W
R352 1-216-841-11 METAL CHIP 47K 5% 1/10W
R353 1-216-817-11 METAL CHIP 470 5% 1/10W
R354 1-216-841-11 METAL CHIP 47K 5% 1/10W
R355 1-216-821-11 METAL CHIP 1K 5% 1/10W
R356 1-216-821-11 METAL CHIP 1K 5% 1/10W
R357 1-216-841-11 METAL CHIP 47K 5% 1/10W
R358 1-216-841-11 METAL CHIP 47K 5% 1/10W
R359 1-216-821-11 METAL CHIP 1K 5% 1/10W
R360 1-216-821-11 METAL CHIP 1K 5% 1/10W
R361 1-216-841-11 METAL CHIP 47K 5% 1/10W
PANEL
