Sony HCD-EC79 - PT-SWITCH, REG, and USB Board Parts List

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69/EC79/EC99
62
PT-SWITCH BOARD
(EC69: E2, E51/EC79: E2, E51/EC99: E2, E51)
****************
< CAPACITOR >
C051 1-165-621-91 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
* CN051 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
CN052 1-820-973-11 HOLDER, CABLE 10P (EC99: E2, E51)
CN053 1-819-972-11 HOLDER, CABLE 8P
(EC69: E2, E51/EC79: E2, E51)
< DIODE >
D051 6-500-334-01 DIODE MC2836-T112-1
D052 6-500-335-01 DIODE MC2838-T112-1
D053 6-500-335-01 DIODE MC2838-T112-1
< TRANSFORMER >
0 PT051 1-445-105-11 TRANSFORMER, POWER
< RELAY >
0 RY052 1-755-496-11 RELAY
< SWITCH >
0 S051 1-786-408-11 SELECTOR, VOLTAGE (SWS-2301)
(VOLTAGE SELECTOR)
************************************************************
REG BOARD
*********
< CAPACITOR >
C698 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< IC >
IC601 6-713-032-01 IC KIA7809API-U/PF
< CABLE HOLDER >
W610 1-824-027-21
HOLDER, CABLE 3P
************************************************************
A-1599-426-A USB BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-128-995-21 ELECT CHIP 100uF 20% 10V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C111 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C112 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C113 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C114 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C115 1-128-995-21 ELECT CHIP 100uF 20% 10V
C116 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C118 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C119 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C120 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
PT-SWITCH REG
C123 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C141 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C143 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C144 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C147 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN104 1-794-548-21 CONNECTOR, USB (A) (USB)
< DIODE >
D106 8-719-058-24 DIODE RB501V-40TE-17
D107 8-719-058-24 DIODE RB501V-40TE-17
D108 6-501-716-01 DIODE MAZ8036GLLS0
D109 6-501-716-01 DIODE MAZ8036GLLS0
D110 8-719-062-51 DIODE 1PS226-115
D113 8-719-062-51 DIODE 1PS226-115
< JUMPER RESISTOR/FERRITE BEAD >
FB101 1-216-295-91 SHORT CHIP 0
FB102 1-216-295-91 SHORT CHIP 0
FB103 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC101 6-713-387-01 IC BU81438JKV-E2
< COIL >
L102 1-457-223-1
1 COMMON MODE CHOKE COIL
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-845-11 METAL CHIP 100K 5% 1/10W
R113 1-216-864-11 SHORT CHIP 0
R123 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
R124 1-216-857-11 METAL CHIP 1M 5% 1/10W
R125 1-216-809-11 METAL CHIP 100 5% 1/10W
R126 1-216-809-11 METAL CHIP 100 5% 1/10W
R127 1-216-809-11 METAL CHIP 100 5% 1/10W
R128 1-216-864-11 SHORT CHIP 0
R129 1-216-864-11 SHORT CHIP 0
R146 1-216-864-11 SHORT CHIP 0
R147 1-216-864-11 SHORT CHIP 0
R151 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
*************************************************************
USB
