10
HCD-EP414
3-6. Cassette Door Assy
1
Open the cassette door assy.
3
cassette door assy
claw
2
3-5. Tape Mechanism Deck (CMAL1Z240A)
1
w
ire (flat type) 8p
2
three screws
(+BVTP 3
×
10
)
3
tape mechanism deck
(CMAL1Z240A)
jomi
