HCD-EP414
3-7. POWER Board, MAIN Board
1
connector
(AC IN)
2
connector
(CN901)
5
two screws
(+BVTP 3
×
10)
3
four screws
(+BVTP 4
×
12)
6
MAIN board
4
POWER board
