Sony HCD-EP414 - DIAGRAMS AND SCHEMATICS; Circuit Board Locations; Diagram Notes and Symbols

15
HCD-EP414
SECTION 6
DIAGRAMS
• Circuit Boards Location
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed
in each block.)
For schematic diagrams.
Note:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
• C : panel designation.
For printed wiring boards.
Note:
• X : parts extracted from the component side.
• Y : parts extracted from the conductor side.
•
f
: internal component.
• : Pattern from the side which enables seeing.
• Indication of transistor
• A : B+ Line.
• B : B– Line.
•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
•Abbreviation
AUS:Australian model
MX : Mexican model
• Signal path.
F : TUNER
J : CD
d : AUX
E : PB (TAPE)
a : REC (TAPE)
CD board
MAIN board
REGULATOR board
BACK LIGHT board
POWER board
CONTROL board
HEADPHONE board
Note:
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
C
B
These are omitted.
E
Q
jomi
