SECTION 8
ELECTRICAL PARTS LIST
34
HCD-EP414
When indicating parts by reference number,
please include the board name.
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•Abbreviation
AUS: Australian model
E2 : 120V AC Area in E models
E51 : Chilean and Peruvian models
MX : Mexican model
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
1-688-190-11 BACKLIGHT BOARD
****************
< DIODE >
D701 8-719-075-50 DIODE SELS6B14C-TP5
D702 8-719-075-50 DIODE SELS6B14C-TP5
D703 8-719-075-50 DIODE SELS6B14C-TP5
< RESISTOR >
R707 1-216-813-11 METAL CHIP 220 5% 1/16W
R708 1-216-813-11 METAL CHIP 220 5% 1/16W
R709 1-216-813-11 METAL CHIP 220 5% 1/16W
R710 1-216-813-11 METAL CHIP 220 5% 1/16W
R711 1-216-813-11 METAL CHIP 220 5% 1/16W
R712 1-216-813-11 METAL CHIP 220 5% 1/16W
************************************************************
A-4728-536-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C103 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C104 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C109 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C110 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C111 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C112 1-115-156-11 CERAMIC CHIP 1uF 10V
C114 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C116 1-126-382-11 ELECT 100uF 20.00% 16V
C117 1-126-382-11 ELECT 100uF 20.00% 16V
C118 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C121 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C122 1-126-933-11 ELECT 100uF 20.00% 16V
C123 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C124 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C125 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C126 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C127 1-126-382-11 ELECT 100uF 20.00% 16V
C130 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C131 1-126-933-11 ELECT 100uF 20.00% 16V
C133 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C140 1-115-156-11 CERAMIC CHIP 1uF 10V
C143 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C145 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C146 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C150 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C153 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C159 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C162 1-126-382-11 ELECT 100uF 20.00% 16V
C163 1-126-933-11 ELECT 100uF 20.00% 16V
C165 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C167 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C168 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C171 1-115-412-11 CERAMIC CHIP 680PF 5.00% 25V
C172 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C181 1-115-412-11 CERAMIC CHIP 680PF 5.00% 25V
C182 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C183 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C184 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C185 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C190 1-115-156-11 CERAMIC CHIP 1uF 10V
C191 1-126-933-11 ELECT 100uF 20.00% 16V
C192 1-126-382-11 ELECT 100uF 20.00% 16V
C193 1-126-382-11 ELECT 100uF 20.00% 16V
C194 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C196 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C197 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C198 1-126-933-11 ELECT 100uF 20.00% 16V
C199 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
< CONNECTOR >
CN101 1-770-528-31 CONNECTOR, FFC/FPC 21P
CN102 1-779-553-21 CONNECTOR,FFC(LIF(NON-ZIF))16P
< DIODE >
D101 8-719-056-77 DIODE UDZ-TE-17-3.9B
< FERRITE BEAD >
FB101 1-469-144-21 FERRITE 0uH
FB103 1-469-144-21 FERRITE 0uH
< IC >
IC101 8-752-402-31 IC CXD3017Q
IC102 8-759-549-28 IC BA5974FP-E2
IC103 8-752-089-74 IC CXA2581N-T4
< JUMPER RESISTOR >
JR101 1-216-864-11 METAL CHIP 0 5% 1/16W
CDBACK LIGHT
