35
HCD-EP414
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< TRANSISTOR >
Q101 8-729-049-31 TRANSISTOR 2SB710A-RTX
Q102 8-729-920-85 TRANSISTOR 2SD1664-T100-QR
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/16W
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-835-11 METAL CHIP 15K 5% 1/16W
R104 1-216-839-11 METAL CHIP 33K 5% 1/16W
R106 1-216-821-11 METAL CHIP 1K 5% 1/16W
R107 1-216-833-11 METAL CHIP 10K 5% 1/16W
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R109 1-216-857-11 METAL CHIP 1M 5% 1/16W
R111 1-216-846-11 METAL CHIP 120K 5% 1/16W
R114 1-218-745-11 METAL CHIP 160K 5% 1/10W
R116 1-216-797-11 METAL CHIP 10 5% 1/16W
R117 1-216-821-11 METAL CHIP 1K 5% 1/16W
R118 1-216-809-11 METAL CHIP 100 5% 1/16W
R119 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R120 1-216-835-11 METAL CHIP 15K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-845-11 METAL CHIP 100K 5% 1/16W
R143 1-216-836-11 METAL CHIP 18K 5% 1/16W
R144 1-216-836-11 METAL CHIP 18K 5% 1/16W
R147 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R148 1-216-797-11 METAL CHIP 10 5% 1/16W
R149 1-216-797-11 METAL CHIP 10 5% 1/16W
R150 1-216-833-11 METAL CHIP 10K 5% 1/16W
R151 1-216-845-11 METAL CHIP 100K 5% 1/16W
R158 1-216-837-11 METAL CHIP 22K 5% 1/16W
R159 1-216-837-11 METAL CHIP 22K 5% 1/16W
R162 1-216-847-11 METAL CHIP 150K 5% 1/16W
R171 1-216-837-11 METAL CHIP 22K 5% 1/16W
R172 1-216-837-11 METAL CHIP 22K 5% 1/16W
R173 1-216-837-11 METAL CHIP 22K 5% 1/16W
R181 1-216-837-11 METAL CHIP 22K 5% 1/16W
R182 1-216-837-11 METAL CHIP 22K 5% 1/16W
R183 1-216-837-11 METAL CHIP 22K 5% 1/16W
R190 1-216-813-11 METAL CHIP 220 5% 1/16W
R191 1-216-839-11 METAL CHIP 33K 5% 1/16W
R192 1-216-839-11 METAL CHIP 33K 5% 1/16W
R193 1-216-846-11 METAL CHIP 120K 5% 1/16W
R194 1-216-845-11 METAL CHIP 100K 5% 1/16W
R195 1-216-853-11 METAL CHIP 470K 5% 1/16W
R196 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R197 1-216-821-11 METAL CHIP 1K 5% 1/16W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION
< VIBRATOR >
X101 1-767-226-11 VIBRATOR, CRYSTAL 16.9344MHz
************************************************************
A-4748-214-A CONTROL BOARD, COMPLETE (E2,E51,MX)
A-4748-614-A CONTROL BOARD, COMPLETE (AEP,AUS)
*************************
4-245-030-01 HOLDER LCD
4-245-801-01 SHEET, LED
4-248-364-01 CUSHION LIGHT
4-248-365-01 SHEET PLATE
4-248-366-01 SHEET LIGHT
< CAPACITOR >
C801 1-162-975-11 CERAMIC CHIP 24PF 5.00% 50V
C802 1-162-975-11 CERAMIC CHIP 24PF 5.00% 50V
C803 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C807 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C808 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C809 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C810 1-126-514-11 ELECT 22uF 20.00% 6.3V
C811 1-126-514-11 ELECT 22uF 20.00% 16V
C812 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C813 1-164-160-11 CERAMIC CHIP 20PF 5.00% 50V
C814 1-164-160-11 CERAMIC CHIP 20PF 5.00% 50V
C815 1-115-871-11 ELECT 1uF 20.00% 50V
C816 1-115-871-11 ELECT 1uF 20.00% 50V
C823 1-126-935-11 ELECT 470uF 20.00% 6.3V
C824 1-126-513-11 ELECT 47uF 20.00% 6.3V
C825 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C826 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C828 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C829 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C830 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C831 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C832 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
< DIODE >
D801 8-719-991-33 DIODE 1SS133T-77
D806 8-719-060-44 DIODE SLR-342VRT32 (STANDBY)
D807 8-719-991-33 DIODE 1SS133T-77
D808 8-719-991-33 DIODE 1SS133T-77
D809 8-719-991-33 DIODE 1SS133T-77
D810 8-719-991-33 DIODE 1SS133T-77
D811 8-719-991-33 DIODE 1SS133T-77
D812 8-719-991-33 DIODE 1SS133T-77
< IC >
IC801 6-802-945-01 IC LC877356A-51E1
IC802 8-759-827-69 IC NJL63H400A-1 ( )
IC803 8-759-637-58 IC PST592C-T
< COIL >
L801 1-410-328-31 INDUCTOR 10uH
< LIQUID CRYSTAL DISPLAY >
LCD801 1-805-198-11 DISPLAY PANEL, LIQUID CRYSTAL
CD CONTROL
