HCD-EP414
SECTION 3
DISASSEMBLY
• This set can be disassembled in the order shown below.
REAR CABINET
BASE UNIT
(BU-K7BD44B)
CONTROL BOARD,
BACK LIGHT BOARD
POWER BOARD , MAIN BOARD
TAPE MECHANISM DECK
(CMAL1Z240A)
CASSETTE DOOR ASSY
SET
CD CABINET SECTION,
FRONT PANEL SECTION
