HCD-EP414
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
PHONE BOARD
************
< CONNECTOR >
CN309 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
< JACK >
J301 1-816-219-11 JACK, HEADPHONE (PHONES)
************************************************************
1-688-188-11 POWER BOARD
*************
< CAPACITOR >
C905 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C905 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
C906 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C906 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
C907 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C907 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
C908 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C908 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
C909 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C909 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
C910 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C910 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
C911 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C911 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
C912 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT MX)
C912 1-164-097-11 CERAMIC 0.022uF 50V
(MX)
< CONNECTOR >
CN901 1-564-509-11 PLUG, CONNECTOR 6P
* CN902 1-691-756-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-063-79 DIODE 1N4002B
D908 8-719-063-79 DIODE 1N4002B
D909 8-719-063-79 DIODE 1N4002B
D910 8-719-063-79 DIODE 1N4002B
D911 8-719-063-79 DIODE 1N4002B
D912 8-719-063-79 DIODE 1N4002B
D913 8-719-063-79 DIODE 1N4002B
POWER REGULATOR
D914 8-719-063-79 DIODE 1N4002B
D916 8-719-046-47 DIODE 1N5401M (EXCEPT MX)
D916 8-719-902-17 DIODE 1N5401 (MX)
D917 8-719-046-47 DIODE 1N5401M (EXCEPT MX)
D917 8-719-902-17 DIODE 1N5401 (MX)
D918 8-719-046-47 DIODE 1N5401M (EXCEPT MX)
D918 8-719-902-17 DIODE 1N5401 (MX)
D919 8-719-046-47 DIODE 1N5401M (EXCEPT MX)
D919 8-719-902-17 DIODE 1N5401 (MX)
D920 8-719-991-33 DIODE 1SS133T-77
D921 8-719-991-33 DIODE 1SS133T-77
< LINE FILTER >
0 LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< RESISTOR >
R901 1-249-437-11 CARBON 47K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
0 R911 1-219-237-51 CARBON 3.3M 5% 1/2W
(MX)
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0 T901 1-439-738-11 TRANSFORMER, POWER (AEP)
0 T901 1-439-781-11 TRANSFORMER, POWER (MX)
0 T901 1-439-772-11 TRANSFORMER, POWER (E2,E51,AUS)
0 T902 1-439-737-11 TRANSFORMER, POWER (AEP)
0 T902 1-439-770-11 TRANSFORMER, POWER (EXCEPT AEP)
************************************************************
1-688-191-11 REGULATOR BOARD
*****************
< IC >
IC305 8-759-347-18 IC KIA7809PI
************************************************************
MISCELLANEOUS
*************
0 8 1-769-744-52 CORD, POWER (AEP,E51)
0 8 1-775-790-31 CORD, POWER (AUS)
0 8 1-827-226-11 CORD, POWER (E2,MX)
11 1-693-619-11 TUNER (FM/AM) (AEP)
11 1-693-620-11 TUNER (FM/AM) (E51,AUS)
11 1-693-624-11 TUNER (FM/AM) (E2,MX)
65 1-796-351-51 MECHANISM, SIGNAL CASSETTE
(CMAL1Z-236A)
69 1-688-190-11 BACK LIGHT BOARD
0 607 8-820-221-01 DEVICE,OPTICAL KSM-213EDP
(including M101,M102)
609 1-757-055-11 WIRE, PARALLEL (FFC) (16 CORE)
S800 1-692-960-11 SWITCH, PUSH (1 KEY)
PHONE
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
