HCD-EX100
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R364 1-216-025-11 RES-CHIP 100 5% 1/10W
R365 1-216-025-11 RES-CHIP 100 5% 1/10W
R381 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R382 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R383 1-216-073-91 RES-CHIP 10K 5% 1/10W
R384 1-216-073-91 RES-CHIP 10K 5% 1/10W
R401 1-216-025-11 RES-CHIP 100 5% 1/10W
R402 1-216-025-11 RES-CHIP 100 5% 1/10W
R403 1-216-025-11 RES-CHIP 100 5% 1/10W
R404 1-216-025-11 RES-CHIP 100 5% 1/10W
R405 1-216-073-91 RES-CHIP 10K 5% 1/10W
R406 1-216-073-91 RES-CHIP 10K 5% 1/10W
R407 1-216-049-11 RES-CHIP 1K 5% 1/10W
(AEP,UK)
R408 1-216-073-91 RES-CHIP 10K 5% 1/10W
(AEP,UK)
0 R409 1-212-881-11 FUSIBLE 100 5% 1/4W
(AEP,UK)
R411 1-216-049-11 RES-CHIP 1K 5% 1/10W
R412 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R413 1-216-049-11 RES-CHIP 1K 5% 1/10W
R414 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R452 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
(AEP,UK)
R453 1-216-049-11 RES-CHIP 1K 5% 1/10W
(AEP,UK)
R454 1-216-033-00 METAL CHIP 220 5% 1/10W
(AEP,UK)
R455 1-216-033-00 METAL CHIP 220 5% 1/10W
(AEP,UK)
R501 1-216-097-11 RES-CHIP 100K 5% 1/10W
R502 1-216-073-91 RES-CHIP 10K 5% 1/10W
R503 1-216-089-91 RES-CHIP 47K 5% 1/10W
R504 1-216-025-11 RES-CHIP 100 5% 1/10W
R505 1-216-049-11 RES-CHIP 1K 5% 1/10W
R511 1-500-445-21 FERRITE 0
R512 1-500-445-21 FERRITE 0
R551 1-216-097-11 RES-CHIP 100K 5% 1/10W
R552 1-216-073-91 RES-CHIP 10K 5% 1/10W
R553 1-216-089-91 RES-CHIP 47K 5% 1/10W
R554 1-216-025-11 RES-CHIP 100 5% 1/10W
R555 1-216-049-11 RES-CHIP 1K 5% 1/10W
R701 1-216-109-00 METAL CHIP 330K 5% 1/10W
R702 1-216-097-11 RES-CHIP 100K 5% 1/10W
R703 1-216-097-11 RES-CHIP 100K 5% 1/10W
R704 1-216-089-91 RES-CHIP 47K 5% 1/10W
R705 1-216-085-91 RES-CHIP 33K 5% 1/10W
(US,CND)
R705 1-216-081-00 METAL CHIP 22K 5% 1/10W
(HK,KR,SP,CH
R705 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(AEP,UK)
R706 1-216-073-91 RES-CHIP 10K 5% 1/10W
R707 1-216-073-91 RES-CHIP 10K 5% 1/10W
R708 1-216-073-91 RES-CHIP 10K 5% 1/10W
R709 1-216-073-91 RES-CHIP 10K 5% 1/10W
R710 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R751 1-216-025-11 RES-CHIP 100 5% 1/10W
R752 1-216-049-11 RES-CHIP 1K 5% 1/10W
R753 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R754 1-216-089-91 RES-CHIP 47K 5% 1/10W
R755 1-216-089-91 RES-CHIP 47K 5% 1/10W
R756 1-216-073-91 RES-CHIP 10K 5% 1/10W
R757 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R774 1-216-073-00 RES-CHIP 10K 5% 1/10W
R775 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R776 1-216-073-91 RES-CHIP 10K 5% 1/10W
R777 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R778 1-216-037-00 METAL CHIP 330 5% 1/10W
R785 1-216-049-11 RES-CHIP 1K 5% 1/10W
R792 1-216-097-11 RES-CHIP 100K 5% 1/10W
R793 1-216-097-11 RES-CHIP 100K 5% 1/10W
R794 1-216-097-11 RES-CHIP 100K 5% 1/10W
< VIBRATOR >
X361 1-579-280-31 VIBRATOR, CRYSTAL (16.9344MHz)
X601 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)(AEP,UK)
X701 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32KHz)
*******************************************************
1-682-069-11 PANEL BOARD
***********
< CAPACITOR >
C606 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C611 1-124-589-11 ELECT 47uF 20% 16V
C612 1-124-589-11 ELECT 47uF 20% 16V
C613 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN601 1-568-850-11 SOCKET, CONNECTOR 7P
* CN602 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D621 8-719-056-11 DIODE SML72423C-TP15 (`/1)
< IC >
IC601 8-742-129-00 IC SBX1971-51P
< TRANSISTOR >
Q622 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q623 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q651 8-729-900-53 TRANSISTOR DTC114EK
Q652 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R601 1-216-041-00 METAL CHIP 470 5% 1/10W
R602 1-216-045-00 METAL CHIP 680 5% 1/10W
R603 1-216-049-11 RES-CHIP 1K 5% 1/10W
R606 1-216-017-91 RES-CHIP 47 5% 1/10W
R609 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R611 1-216-041-00 METAL CHIP 470 5% 1/10W
R612 1-216-045-00 METAL CHIP 680 5% 1/10W
R613 1-216-049-11 RES-CHIP 1K 5% 1/10W
R614 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R615 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
PANEL
To Next Page
