HCD-EX100
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
POWER
R616 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R619 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R622 1-216-041-00 METAL CHIP 470 5% 1/10W
R623 1-216-037-00 METAL CHIP 330 5% 1/10W
< SWITCH >
S601 1-762-875-21 SWITCH, KEYBOARD (`/1)
S602 1-571-532-21 SWITCH, TACTIL (DISPLAY)
S603 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S604 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S611 1-762-875-21 SWITCH, KEYBOARD (u)
S612 1-762-875-21 SWITCH, KEYBOARD (x)
S613 1-762-875-21 SWITCH, KEYBOARD (TUNING -.m)
S614 1-762-875-21 SWITCH, KEYBOARD (TUNING +M >)
S615 1-762-875-21 SWITCH, KEYBOARD (VOL -)
S616 1-762-875-21 SWITCH, KEYBOARD (VOL +)
< TEST PIN >
TP603 1-690-880-51 LEAD (WITH CONNECTOR)
******************************************************
A-4725-964-A POWER BOARD, COMPLETE (US,CND)
A-4725-972-A POWER BOARD, COMPLETE (AEP,UK)
A-4725-976-A POWER BOARD, COMPLETE (HK,KR,SP)
A-4726-857-A POWER BOARD, COMPLETE (CH)
*****************************
1-533-293-11 FUSE HOLDER
4-224-739-01 CASE (TR), RUBBER
4-224-742-01 TUBE, RUBBER
4-224-743-01 RETAINER, IC
7-685-132-19 SCREW +P 2.6X5 TYPE2 NON-SLIT
< CAPACITOR >
C1 1-131-678-11 ELECT 82uF 20% 400V
(HK,KR,SP,CH)
C1 1-107-956-11 ELECT 220uF 20% 200V
(US,CND)
C1 1-131-714-11 ELECT 100uF 20% 400V
(AEP,UK)
C2 1-107-888-11 ELECT 47uF 20% 25V
C3 1-130-477-00 MYLAR 0.0033uF 5% 50V
C4 1-107-429-11 CERAMIC 0.0022uF 10% 1KV
C5 1-162-290-31 CERAMIC 470PF 10% 50V
C6 1-131-983-11 FILM 0.1uF 10% 275V
C7 1-131-983-11 FILM 0.1uF 10% 275V
C9 1-113-907-51 CERAMIC 0.0022uF 99% 250V
C10 1-162-115-00 CERAMIC 330PF 10% 2KV
C11 1-113-920-11 CERAMIC 0.0022uF 20% 250V
C12 1-113-920-11 CERAMIC 0.0022uF 20% 250V
C13 1-131-678-11 ELECT 82uF 20% 400V
(HK,KR,SP)
C13 1-131-714-11 ELECT 100uF 20% 400V
(AEP,UK,CH)
C14 1-113-920-11 CERAMIC 0.0022uF 20% 250V
C21 1-164-159-11 CERAMIC 0.1uF 50V
C901 1-107-425-11 CERAMIC 470PF 10% 1KV
C902 1-131-969-11 ELECT 1800uF 20% 25V
C903 1-131-970-11 ELECT 1500uF 20% 25V
C904 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C905 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C911 1-107-425-11 CERAMIC 470PF 10% 1KV
C912 1-131-969-11 ELECT 1800uF 20% 25V
C913 1-131-970-11 ELECT 1500uF 20% 25V
C914 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C915 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C931 1-107-425-11 CERAMIC 470PF 10% 1KV
C932 1-126-768-11 ELECT 2200uF 20% 16V
C939 1-124-995-11 ELECT 220uF 20% 10V
C940 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C941 1-107-425-11 CERAMIC 470PF 10% 1KV
C942 1-126-012-11 ELECT 470uF 20% 16V
C949 1-124-995-11 ELECT 220uF 20% 10V
C950 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C951 1-136-153-00 FILM 0.01uF 5% 50V
C952 1-162-292-31 CERAMIC 680PF 10% 50V
< CONNECTOR >
* CN1 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN903 1-764-334-11 PLUG, CONNECTOR 11P
< DIODE >
D2 8-719-200-93 DIODE 11EQS10-TA2
D3 8-719-200-93 DIODE 11EQS10-TA2
D4 8-719-210-21 DIODE 11EQS04
D6 8-719-109-97 DIODE RD6.8ESB2
D7 8-719-911-19 DIODE 1SS119-25
D10 8-719-084-21 DIODE 10E6N-TA1B2
D11 8-719-084-21 DIODE 10E6N-TA1B2
D12 8-719-084-21 DIODE 10E6N-TA1B2
D13 8-719-084-21 DIODE 10E6N-TA1B2
D21 8-719-048-55 DIODE MTZJ-T-77-10C
D22 8-719-110-53 DIODE RD20ESB2
D901 8-719-043-52 DIODE F5KQ60
D911 8-719-043-52 DIODE F5KQ60
D931 8-719-210-21 DIODE 11EQS04
D941 8-719-210-21 DIODE 11EQS04
D951 8-719-911-19 DIODE 1SS119-25
D952 8-719-911-19 DIODE 1SS119-25
D953 8-719-200-93 DIODE 11EQS10-TA2
D954 8-719-200-93 DIODE 11EQS10-TA2(AEP,UK,HK,KR,SP,CH)
< GROUND TERMINAL >
EPT1 1-537-770-21 TERMINAL BOARD, GROUND
EPT2 1-537-770-21 TERMINAL BOARD, GROUND (US,CND)
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
< FUSE >
0 F1 1-533-451-11 FUSE, GLASS TUBE (DIA. 5) (3.15A/125V)
(US,CND)
0 F1 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V)
(AEP,UK,HK,KR,SP,CH)
< FERRITE BEAD >
FB1 1-412-473-21 INDUCTOR 0uH
