45
HCD-EX100
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
POWER
< IC >
IC1 8-749-019-48 IC STR-F6676-LF1352
IC933 8-759-288-53 IC LA5617
IC951 8-749-016-65 IC SE015N
< COIL >
L1 1-419-528-11 INDUCTOR 13mH
L901 1-419-281-11 INDUCTOR 10uH
L911 1-419-281-11 INDUCTOR 10uH
< ISOLATER >
PC1 8-749-013-68 IC PS2561-1-D
PC2 8-749-013-68 IC PS2561-1-D
< TRANSISTOR >
Q21 8-729-111-29 TRANSISTOR 2SD1616A-K
Q22 8-729-140-04 TRANSISTOR 2SB1116A-L
Q23 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q951 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
0 R1 1-219-237-11 SOLID 3.3M 20% 1/2W
(US,CND)
R2 1-249-426-11 CARBON 5.6K 5% 1/4W
R3 1-247-843-11 CARBON 3.3K 5% 1/4W
R4 1-249-415-11 CARBON 680 5% 1/4W
0 R5 1-217-151-00 METAL 0.22 10% 2W
0 R8 1-249-393-11 CARBON 10 5% 1/4W
0 R9 1-215-903-11 METAL OXIDE 68K 5% 2W
R10 1-247-895-00 CARBON 470K 5% 1/4W
R11 1-249-433-11 CARBON 22K 5% 1/4W
R21 1-249-425-11 CARBON 4.7K 5% 1/4W
R22 1-249-424-11 CARBON 3.9K 5% 1/4W
R23 1-247-881-00 CARBON 120K 5% 1/4W
R24 1-249-439-11 CARBON 68K 5% 1/4W
0 R939 1-219-119-81 FUSIBLE 0.1 5% 1/4W
0 R949 1-219-119-81 FUSIBLE 0.1 5% 1/4W
R951 1-249-419-11 CARBON 1.5K 5% 1/4W
R952 1-249-401-11 CARBON 47 5% 1/4W
R953 1-249-420-11 CARBON 1.8K 5% 1/4W
R954 1-249-437-11 CARBON 47K 5% 1/4W
R955 1-249-425-11 CARBON 4.7K 5% 1/4W
R956 1-249-415-11 CARBON 680 5% 1/4W
R957 1-249-409-11 CARBON 220 5% 1/4W
(AEP,UK,HK,KR,SP,CH)
< TRANSFORMER >
0 T901 1-435-130-11 TRANSFORMER, POWER
< THERMISTOR >
0 TH1 1-803-806-31 THERMISTOR, NTC
******************************************************
A-4725-969-A REG BOARD, COMPLETE (US,CND)
A-4725-974-A REG BOARD, COMPLETE (AEP,UK)
A-4725-978-A REG BOARD, COMPLETE (HK,KR,SP)
A-4726-859-A REG BOARD, COMPLETE (CH)
***************************
< CAPACITOR >
C891 1-164-159-11 CERAMIC 0.1uF 50V
C892 1-164-159-11 CERAMIC 0.1uF 50V
C893 1-164-159-11 CERAMIC 0.1uF 50V
C894 1-164-159-11 CERAMIC 0.1uF 50V
C895 1-164-159-11 CERAMIC 0.1uF 50V
C896 1-164-159-11 CERAMIC 0.1uF 50V
C897 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AEP,UK,CH)
C898 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AEP,UK,CH)
C899 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AEP,UK,CH)
C900 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(AEP,UK,CH)
C933 1-164-346-11 CERAMIC CHIP 1uF 16V
C934 1-126-926-11 ELECT 1000uF 20% 10V
C935 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C936 1-126-964-11 ELECT 10uF 20% 50V
C937 1-126-926-11 ELECT 1000uF 20% 10V
C961 1-126-967-11 ELECT 47uF 20% 50V
C962 1-164-159-11 CERAMIC 0.1uF 50V
C963 1-126-967-11 ELECT 47uF 20% 50V
< CONNECTOR >
* CN901 1-568-832-11 SOCKET, CONNECTOR 13P
< DIODE >
D933 8-719-988-61 DIODE 1SS355TE-17
D934 8-719-200-82 DIODE 11ES2
D961 8-719-986-26 DIODE HZS12A3LTA
< FERRITE BEAD >
FB891 1-412-473-21 INDUCTOR 0UH (AEP,UK,CH)
FB892 1-412-473-21 INDUCTOR 0UH (AEP,UK,CH)
< IC >
IC931 8-759-460-76 IC BA07FP-E2
IC932 8-759-231-53 IC M5F7805L
< TRANSISTOR >
Q961 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q962 8-729-202-67 TRANSISTOR 2SK246-GR3
Q963 8-729-900-53 TRANSISTOR DTC114EK
Q964 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R891 1-249-393-11 CARBON 10 5% 1/4W
R892 1-249-393-11 CARBON 10 5% 1/4W
R893 1-216-001-00 METAL CHIP 10 5% 1/10W
(AEP,UK,CH)
R894 1-216-001-00 METAL CHIP 10 5% 1/10W
(AEP,UK,CH)
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
REG
