46
HCD-EX100
R961 1-216-073-91 RES-CHIP 10K 5% 1/10W
R962 1-216-049-11 RES-CHIP 1K 5% 1/10W
R963 1-249-417-11 CARBON 1K 5% 1/4W
< TERMINAL >
TM801 1-537-238-11 TERMINAL BOARD
******************************************************
1-682-073-11 SW BOARD
********
< SWITCH >
S351 1-786-154-11 SWITCH, ROTARY (OPEN/CLOSE)
******************************************************
MISCELLANEOUS
***************
15 1-769-889-11 WIRE (FLAT TYPE) (7 CORE)
18 1-754-208-11 ANTENNA, FM (US,CND)
18 1-754-209-11 ANTENNA, FM (AEP,UK,CH,HK,KR,SP)
0 60 1-757-316-11 CORD, POWER (AEP,HK,SP,UK)
0 60 1-769-079-11 CORD, POWER (KR)
0 60 1-782-464-21 CORD, POWER (CH)
0 60 1-783-531-31 CORD, POWER (US,CND)
62 1-791-698-11 WIRE (FLAT TYPE) (16 CORE)
63 1-769-973-11 WIRE (FLAT TYPE) (13 CORE)
64 1-693-407-13 TUNER (US,CND)
64 1-693-408-12 TUNER (AEP,UK,HK,CH,KR,SP)
0 65 1-569-008-21 ADAPTOR, CONVERSION (HK,SP)
0 66 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK,UK)
127 1-769-973-11 WIRE (FLAT TYPE) (13 CORE)
152 A-4909-346-A BASE UNIT (KSM-770ACA)
LCD701 1-804-474-11 DISPLAY PANEL, LIQUID CRYSTAL
M351 X-4952-498-1 MOTOR ASSY
***********************************************************************************
Ref. No. Part No. Description Remark
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
SW
REG
Ref. No. Part No. Description Remark
****************
HARDWARE LIST
****************
#1 7-685-870-01 SCREW +BVTT 3X5 (S)
#2 7-685-246-14 SCREW +KTP 3X8 TYPE2 NON-SLIT
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#4 7-621-775-08 SCREW +B 2.6X3
#5 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S
#6 7-685-132-19 SCREW +P 2.6X5 TYPE2 NON-SLIT
#7 7-624-105-04 STOP RING 2.3, TYPE -E
