Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
150
HCD-FLX5D/FXL7D
MC MIC OUT/MIDOUT SW
R262 1-216-841-11 METAL CHIP 47K 5% 1/10W
R263 1-216-841-11 METAL CHIP 47K 5% 1/10W
R264 1-216-841-11 METAL CHIP 47K 5% 1/10W
R265 1-216-821-11 METAL CHIP 1K 5% 1/10W
R266 1-216-841-11 METAL CHIP 47K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R272 1-216-864-11 SHORT CHIP 0
R273 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X101 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X102 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
************************************************************
A-4750-814-A MIC BOARD, COMPLETE (EXCEPT FLX5D: TH)
A-4753-582-A MIC BOARD, COMPLETE (FLX5D: TH)
********************
< CAPACITOR >
C351 1-126-957-11 ELECT 0.22uF 20% 50V
C352 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C353 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C354 1-126-964-11 ELECT 10uF 20% 50V
C355 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C356 1-126-956-11 ELECT 0.1uF 20% 50V
C357 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C358 1-126-961-11 ELECT 2.2uF 20% 50V
C359 1-162-949-11 CERAMIC CHIP 47PF 5% 50V
C360 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C361 1-126-961-11 ELECT 2.2uF 20% 50V
C362 1-126-964-11 ELECT 10uF 20% 50V
C363 1-126-964-11 ELECT 10uF 20% 50V
C364 1-126-964-11 ELECT 10uF 20% 50V
C365 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C366 1-115-872-11 ELECT 2.2uF 20% 50V
C367 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C368 1-115-871-11 ELECT 1uF 20% 50V
C369 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C370 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C371 1-136-495-11 FILM 0.068uF 5% 50V
C372 1-126-959-11 ELECT 0.47uF 20% 50V
C373 1-126-959-11 ELECT 0.47uF 20% 50V
C374 1-136-167-00 FILM 0.15uF 5% 50V
C375 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C376 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C377 1-136-495-11 FILM 0.068uF 5% 50V
C378 1-126-947-11 ELECT 47uF 20% 35V
C379 1-126-947-11 ELECT 47uF 20% 35V
C380 1-126-960-11 ELECT 1uF 20% 50V
C381 1-126-933-11 ELECT 100uF 20% 16V
< DIODE >
D351 8-719-069-54 DIODE UDZSTE-175.1B
< SHORT >
FB351 1-216-864-11 SHORT CHIP 0
< IC >
IC351 8-759-711-85 IC NJM4580E-D
IC352 8-759-496-41 IC M65850FP-E1
< JACK >
J351 1-770-226-11 JACK (LARGE TYPE) (MIC)
< TRANSISTOR >
Q351 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R351 1-216-833-11 METAL CHIP 10K 5% 1/10W
R352 1-216-821-11 METAL CHIP 1K 5% 1/10W
R353 1-216-845-11 METAL CHIP 100K 5% 1/10W
R354 1-216-821-11 METAL CHIP 1K 5% 1/10W
R355 1-216-841-11 METAL CHIP 47K 5% 1/10W
R356 1-216-809-11 METAL CHIP 100 5% 1/10W
R357 1-216-833-11 METAL CHIP 10K 5% 1/10W
R358 1-216-847-11 METAL CHIP 150K 5% 1/10W
R359 1-216-809-11 METAL CHIP 100 5% 1/10W
R360 1-216-833-11 METAL CHIP 10K 5% 1/10W
R361 1-216-833-11 METAL CHIP 10K 5% 1/10W
R362 1-216-821-11 METAL CHIP 1K 5% 1/10W
R363 1-216-845-11 METAL CHIP 100K 5% 1/10W
R364 1-216-864-11 SHORT CHIP 0
R365 1-216-835-11 METAL CHIP 15K 5% 1/10W
R366 1-216-835-11 METAL CHIP 15K 5% 1/10W
R367 1-216-837-11 METAL CHIP 22K 5% 1/10W
R368 1-216-837-11 METAL CHIP 22K 5% 1/10W
R369 1-216-841-11 METAL CHIP 47K 5% 1/10W
R370 1-216-837-11 METAL CHIP 22K 5% 1/10W
R371 1-216-837-11 METAL CHIP 22K 5% 1/10W
R372 1-216-837-11 METAL CHIP 22K 5% 1/10W
R373 1-216-846-11 METAL CHIP 120K 5% 1/10W
R374 1-216-814-11 METAL CHIP 270 5% 1/10W
R375 1-216-837-11 METAL CHIP 22K 5% 1/10W
< VARIABLE RESISTOR >
RV351 1-223-984-11 RES, VAR, CARBON 50K (MIC LEVEL)
RV352 1-223-984-11 RES, VAR, CARBON 50K (ECHO LEVEL)
************************************************************
1-683-898-11 OUT/MIDOUT SW BOARD
********************
< CONNECTOR >
* CN709 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S701 1-771-218-11 SWITCH, MICRO (MIDOUT)
S702 1-771-218-11 SWITCH, MICRO (LID)
S708 1-771-218-11 SWITCH, MICRO (OUT)
************************************************************
