Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
151
HCD-FLX5D/FXL7D
PANEL (L) PANEL (R) PANEL (U) REGULATOR RF
A-4750-813-A PANEL (L) BOARD, COMPLETE
(EXCEPT FLX5D: TH)
A-4753-580-A PANEL (L) BOARD, COMPLETE (FLX5D: TH)
*************************
< LED >
D301 8-719-058-04 LED SEL5223S-TP15 (I/1)
D302 8-719-071-41 LED SELS5923C-TP15 (DVD)
D303 8-719-071-41 LED SELS5923C-TP15 (TUNER/BAND)
D304 8-719-071-41 LED SELS5923C-TP15 (TAPE A/B)
< RESISTOR >
R301 1-216-813-11 METAL CHIP 220 5% 1/10W
R302 1-216-809-11 METAL CHIP 100 5% 1/10W
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
R307 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R308 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R309 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R338 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE (I/1)
S305 1-771-410-21 SWITCH, TACTILE (DVD)
S306 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S307 1-771-410-21 SWITCH, TACTILE (TAPE A/B)
S326 1-771-410-21 SWITCH, TACTILE (A Z)
************************************************************
A-4750-819-A PANEL (R) BOARD, COMPLETE
(EXCEPT FLX5D: TH)
A-4753-581-A PANEL (R) BOARD, COMPLETE (FLX5D: TH)
*************************
< RESISTOR >
R321 1-216-819-11 METAL CHIP 680 5% 1/10W
R322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R323 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R324 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R325 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R326 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R327 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R328 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
< SWITCH >
S311 1-771-410-21 SWITCH, TACTILE (DISC SELECT)
S312 1-771-410-21 SWITCH, TACTILE (Z)
S313 1-771-410-21 SWITCH, TACTILE (gG)
S314 1-771-410-21 SWITCH, TACTILE (X)
S315 1-771-410-21 SWITCH, TACTILE (x)
S316 1-771-410-21 SWITCH, TACTILE (.)
S317 1-771-410-21 SWITCH, TACTILE (>)
S318 1-771-410-21 SWITCH, TACTILE (– m)
S319 1-771-410-21 SWITCH, TACTILE (+ M)
S324 1-771-410-21 SWITCH, TACTILE (Z B)
************************************************************
PANEL (U) BOARD
***************
< CAPACITOR >
C313 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< JACK >
J301 1-815-603-11 JACK (i)
< RESISTOR >
R305 1-216-819-11 METAL CHIP 680 5% 1/10W
R306 1-216-821-11 METAL CHIP 1K 5% 1/10W
R329 1-216-819-11 METAL CHIP 680 5% 1/10W
R330 1-216-821-11 METAL CHIP 1K 5% 1/10W
R331 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S302 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S303 1-771-410-21 SWITCH, TACTILE (VIDEO (SAT))
S304 1-771-410-21 SWITCH, TACTILE (GROOVE)
S320 1-771-410-21 SWITCH, TACTILE (DIGITAL)
S321 1-771-410-21 SWITCH, TACTILE (REC PAUSE/START)
S322 1-771-410-21 SWITCH, TACTILE (CD SYNC/HI-DUB)
S323 1-771-410-21 SWITCH, TACTILE (EFFECT)
************************************************************
1-684-271-11 REGULATOR BOARD
*****************
< CAPACITOR >
C870 1-115-867-11 ELECT 0.1uF 20% 50V
C871 1-115-867-11 ELECT 0.1uF 20% 50V
C872 1-115-867-11 ELECT 0.1uF 20% 50V
C873 1-115-867-11 ELECT 0.1uF 20% 50V
C878 1-126-791-11 ELECT 10uF 20% 35V
C879 1-126-791-11 ELECT 10uF 20% 35V
C880 1-126-791-11 ELECT 10uF 20% 35V
C881 1-126-791-11 ELECT 10uF 20% 35V
< TRANSISTOR >
Q865 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R871 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R872 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R873 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R887 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
A-4728-690-A RF BOARD, COMPLETE
******************
< CAPACITOR >
C001 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C002 1-124-779-00 ELECT CHIP 10uF 20% 16V
C003 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C004 1-124-779-00 ELECT CHIP 10uF 20% 16V
C005 1-128-993-21 ELECT CHIP 22uF 20% 10V
