98
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN88D
R798 1-216-809-11 METAL CHIP 100 5% 1/10W
R799 1-216-809-11 METAL CHIP 100 5% 1/10W
R800 1-216-841-11 METAL CHIP 47K 5% 1/10W
R801 1-216-817-11 METAL CHIP 470 5% 1/10W
R802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R803 1-216-841-11 METAL CHIP 47K 5% 1/10W
R804 1-216-841-11 METAL CHIP 47K 5% 1/10W
R805 1-216-833-11 METAL CHIP 10K 5% 1/10W
R806 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R807 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R808 1-216-841-11 METAL CHIP 47K 5% 1/10W
R809 1-216-841-11 METAL CHIP 47K 5% 1/10W
R810 1-216-833-11 METAL CHIP 10K 5% 1/10W
R811 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R812 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R813 1-216-833-11 METAL CHIP 10K 5% 1/10W
R814 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R815 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R816 1-216-841-11 METAL CHIP 47K 5% 1/10W
R817 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R818 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-220-373-11 METAL CHIP 620 5% 1/10W
R820 1-220-373-11 METAL CHIP 620 5% 1/10W
R821 1-216-857-11 METAL CHIP 1M 5% 1/10W
R822 1-216-833-11 METAL CHIP 10K 5% 1/10W
R823 1-216-857-11 METAL CHIP 1M 5% 1/10W
R824 1-216-833-11 METAL CHIP 10K 5% 1/10W
R825 1-216-857-11 METAL CHIP 1M 5% 1/10W
R826 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R827 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R828 1-216-841-11 METAL CHIP 47K 5% 1/10W
R829 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R830 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R831 1-216-841-11 METAL CHIP 47K 5% 1/10W
R832 1-216-833-11 METAL CHIP 10K 5% 1/10W
R833 1-216-817-11 METAL CHIP 470 5% 1/10W
R834 1-216-841-11 METAL CHIP 47K 5% 1/10W
R835 1-216-821-11 METAL CHIP 1K 5% 1/10W
R836 1-216-833-11 METAL CHIP 10K 5% 1/10W
R837 1-216-841-11 METAL CHIP 47K 5% 1/10W
R838 1-216-833-11 METAL CHIP 10K 5% 1/10W
R839 1-216-841-11 METAL CHIP 47K 5% 1/10W
R840 1-216-821-11 METAL CHIP 1K 5% 1/10W
R841 1-216-833-11 METAL CHIP 10K 5% 1/10W
R842 1-216-833-11 METAL CHIP 10K 5% 1/10W
R843 1-216-833-11 METAL CHIP 10K 5% 1/10W
R844 1-216-833-11 METAL CHIP 10K 5% 1/10W
R845 1-216-841-11 METAL CHIP 47K 5% 1/10W
R846 1-216-833-11 METAL CHIP 10K 5% 1/10W
R847 1-216-821-11 METAL CHIP 1K 5% 1/10W
R848 1-216-833-11 METAL CHIP 10K 5% 1/10W
R849 1-216-841-11 METAL CHIP 47K 5% 1/10W
R850 1-216-821-11 METAL CHIP 1K 5% 1/10W
R851 1-216-837-11 METAL CHIP 22K 5% 1/10W
R852 1-216-837-11 METAL CHIP 22K 5% 1/10W
R853 1-216-845-11 METAL CHIP 100K 5% 1/10W
R854 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R857 1-216-864-11 METAL CHIP 0 5% 1/10W
R858 1-216-864-11 METAL CHIP 0 5% 1/10W
R860 1-216-841-11 METAL CHIP 47K 5% 1/10W
R861 1-216-833-11 METAL CHIP 10K 5% 1/10W
R862 1-216-841-11 METAL CHIP 47K 5% 1/10W
R863 1-216-833-11 METAL CHIP 10K 5% 1/10W
R904 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R905 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R906 1-216-821-11 METAL CHIP 1K 5% 1/10W
R915 1-216-845-11 METAL CHIP 100K 5% 1/10W
R916 1-216-845-11 METAL CHIP 100K 5% 1/10W
R917 1-216-833-11 METAL CHIP 10K 5% 1/10W
R921 1-216-820-11 METAL CHIP 820 5% 1/10W
R922 1-216-805-11 METAL CHIP 47 5% 1/10W
R923 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
RV301 1-238-019-11 RES, ADJ, CARBON 47K (REC LEVEL(L))
RV304 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS(L))
RV351 1-238-019-11 RES, ADJ, CARBON 47K (REC LEVEL(R))
RV354 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS(R))
RY701 1-755-267-11 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
******************************************************
1-687-133-11 MOTOR (LD) BOARD
****************
******************************************************
1-687-134-11 MOTOR (TB) BOARD
***************
< CONNECTOR >
CN742 1-784-727-11 CONNECTOR, FFC 5P
******************************************************
A-4732-900-A POWER AMP BOARD, COMPLETE (EXCEPT TH)
A-4734-623-A POWER AMP BOARD, COMPLETE (TH)
************************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-286-31 CERAMIC 220PF 10% 50V
C504 1-104-665-11 ELECT 100uF 20% 10V
C507 1-136-495-11 FILM 0.068uF 5% 50V
C508 1-136-495-11 FILM 0.068uF 5% 50V
C509 1-128-560-11 ELECT 22uF 20% 100V
C512 1-162-306-11 CERAMIC 0.01uF 20% 16V
C513 1-162-306-11 CERAMIC 0.01uF 20% 16V
C516 1-104-665-11 ELECT 100uF 20% 10V
C517 1-126-964-11 ELECT 10uF 20% 50V
C523 1-162-306-11 CERAMIC 0.01uF 30% 16V
C524 1-162-306-11 CERAMIC 0.01uF 30% 16V
MAIN MOTOR (LD) MOTOR (TB) POWER AMP
