Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN88D
C525 1-162-306-11 CERAMIC 0.01uF 20% 16V
C526 1-126-964-11 ELECT 10uF 20% 50V
C527 1-162-306-11 CERAMIC 0.01uF 20% 16V
C528 1-162-306-11 CERAMIC 0.01uF 20% 16V
C541 1-136-165-00 FILM 0.1uF 5% 50V
C542 1-127-811-11 ELECT 3300uF 20% 50V
C544 1-130-777-00 MYLAR 0.1uF 5% 100V
C545 1-130-777-00 MYLAR 0.1uF 5% 100V
C546 1-137-843-11 ELECT 2200uF 20% 100V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-286-31 CERAMIC 220PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
C557 1-136-495-11 FILM 0.068uF 5% 50V
C558 1-136-495-11 FILM 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C581 1-126-965-91 ELECT 22uF 20% 50V
C591 1-136-165-00 FILM 0.1uF 5% 50V
C592 1-127-811-11 ELECT 3300uF 20% 50V
C596 1-137-843-11 ELECT 2200uF 20% 100V
< CONNECTOR >
CN502 1-564-509-11 PLUG, CONNECTOR 6P (TH)
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-770-722-11 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-72
D502 8-719-991-33 DIODE 1SS133T-72
D503 8-719-947-70 DIODE MTZJ-T-72-18C
D504 8-719-947-70 DIODE MTZJ-T-72-18C
D506 8-719-991-33 DIODE 1SS133T-72
D507 8-719-991-33 DIODE 1SS133T-72
D508 8-719-991-33 DIODE 1SS133T-72
D509 8-719-991-33 DIODE 1SS133T-72
D511 8-719-991-33 DIODE 1SS133T-72
D541 8-719-060-53 DIODE RBV-2506
D543 8-719-500-60 DIODE D5SBA20
D551 8-719-991-33 DIODE 1SS133T-72
D581 8-719-991-33 DIODE 1SS133T-72
< EARTH TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-017-06 IC STK412-150
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-821-00 TRANSISTOR 2SA1207-AA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q510 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q511 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q514 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q516 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q517 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q518 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-437-11 CARBON 47K 5% 1/4W
R503 1-249-409-11 CARBON 220 5% 1/4W F
R504 1-249-437-11 CARBON 47K 5% 1/4W
R505 1-249-416-11 CARBON 820 5% 1/4W F
R506 1-249-435-11 CARBON 33K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0 R508 1-234-798-11 ENCAPSULATED COMPONENT
R509 1-260-076-11 CARBON 10 5% 1/2W
0 R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0 R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-429-11 CARBON 10K 5% 1/4W
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
0 R520 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-441-11 CARBON 100K 5% 1/4W
0 R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R527 1-249-438-11 CARBON 56K 5% 1/4W
R528 1-249-437-11 CARBON 47K 5% 1/4W
R529 1-249-433-11 CARBON 22K 5% 1/4W
R530 1-249-433-11 CARBON 22K 5% 1/4W
R531 1-247-890-11 CARBON 300K 5% 1/4W
(TH)
R531 1-247-891-00 CARBON 330K 5% 1/4W
(EXCEPT TH)
R532 1-249-441-11 CARBON 100K 5% 1/4W
R533 1-249-437-11 CARBON 47K 5% 1/4W
0 R539 1-215-891-11 METAL OXIDE 680 5% 2W
R541 1-249-441-11 CARBON 100K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R545 1-249-417-11 CARBON 1K 5% 1/4W F
R546 1-249-433-11 CARBON 22K 5% 1/4W
R547 1-249-437-11 CARBON 47K 5% 1/4W
R548 1-249-437-11 CARBON 47K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-437-11 CARBON 47K 5% 1/4W
R553 1-249-409-11 CARBON 220 5% 1/4W F
R554 1-249-437-11 CARBON 47K 5% 1/4W
R555 1-249-416-11 CARBON 820 5% 1/4W F
R556 1-249-435-11 CARBON 33K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0 R558 1-234-798-11 ENCAPSULATED COMPONENT
R559 1-260-076-11 CARBON 10 5% 1/2W
0 R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R564 1-249-433-11 CARBON 22K 5% 1/4W
R565 1-249-433-11 CARBON 22K 5% 1/4W
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
POWER AMP
