HCD-GPZ6/GPZ7
16
3-19. AU-TC BOARD
3-20. MECHANICAL DECK
(CMAL5Z232A)
1 connector
(CN301)
2 screw (B2.6)
3 AU-TC board
1 connector
2 two screws
(B2.6)
1 two screws
(B2.6)
4 screw (B2.6)
6 mechanical deck
(CMAL5Z232A)
5 bracket (CST)
3 screw (B2.6)
