HCD-GPZ6/GPZ7
Pin No. Pin Name I/O Description
87 FAN ON
O
Fan motor drive signal output terminal
88
VOL A I
Jog dial pulse input from the rotary encoder for the VOLUME (A phase input)
89
VOL B I
Jog dial pulse input from the rotary encoder for the VOLUME (B phase input)
90 to 92 KEY3 to KEY1 I
Key input (A/D input) terminal for the front panel
93
SPEC-IN
I Destination setting terminal
94
TC END SW I
Tape end detect sensor input terminal "H" input when the tape end detected
95
TC HALF/REC
SW
I
Cassette in and recording direction detection signal input terminal
"L": side B recording, center voltage: cassette in (stop), "H": side A recording
96 AVSS
-
Ground terminal
97
SEARCH A I
Jog dial pulse input from the rotary encoder (A phase input)
98 VREF I
Reference voltage (+3.3V) input terminal
99
AVCC
-
Power supply terminal (+3.3V)
100
SEARCH B I
Jog dial pulse input from the rotary encoder (B phase input)
