Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
67
HCD-GPZ6/GPZ7
< RESISTOR/FERRITE BEAD >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-809-11 METAL CHIP 100 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R113 1-216-809-11 METAL CHIP 100 5% 1/10W
R114 1-216-864-11 SHORT CHIP 0
R201 1-500-445-21 FERRITE, EMI (SMD) (2012)
R202 1-500-445-21 FERRITE, EMI (SMD) (2012)
R203 1-216-295-00 SHORT CHIP 0
R207 1-216-295-00 SHORT CHIP 0
R249 1-216-841-11 METAL CHIP 47K 5% 1/10W
R250 1-216-857-11 METAL CHIP 1M 5% 1/10W
R252 1-216-833-11 METAL CHIP 10K 5% 1/10W
R253 1-216-821-11 METAL CHIP 1K 5% 1/10W
R254 1-216-833-11 METAL CHIP 10K 5% 1/10W
R255 1-216-821-11 METAL CHIP 1K 5% 1/10W
R256 1-216-837-11 METAL CHIP 22K 5% 1/10W
R257 1-216-853-11 METAL CHIP 470K 5% 1/10W
R258 1-216-849-11 METAL CHIP 220K 5% 1/10W
R259 1-216-833-11 METAL CHIP 10K 5% 1/10W
R260 1-216-864-11 SHORT CHIP 0
R265 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R266 1-216-821-11 METAL CHIP 1K 5% 1/10W
R267 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R268 1-216-833-11 METAL CHIP 10K 5% 1/10W
R269 1-216-809-11 METAL CHIP 100 5% 1/10W
R270 1-216-817-11 METAL CHIP 470 5% 1/10W
R271 1-216-857-11 METAL CHIP 1M 5% 1/10W
R272 1-500-445-21 FERRITE, EMI (SMD) (2012)
R275 1-216-809-11 METAL CHIP 100 5% 1/10W
R276 1-216-841-11 METAL CHIP 47K 5% 1/10W
R277 1-216-809-11 METAL CHIP 100 5% 1/10W
R278 1-216-809-11 METAL CHIP 100 5% 1/10W
R279 1-216-809-11 METAL CHIP 100 5% 1/10W
R291 1-216-809-11 METAL CHIP 100 5% 1/10W
R292 1-216-809-11 METAL CHIP 100 5% 1/10W
R321 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R322 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R323 1-216-864-11 SHORT CHIP 0
R324 1-216-845-11 METAL CHIP 100K 5% 1/10W
R325 1-216-864-11 SHORT CHIP 0
R326 1-216-864-11 SHORT CHIP 0
R401 1-216-295-00 SHORT CHIP 0
R421 1-216-864-11 SHORT CHIP 0
R423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R451 1-216-837-11 METAL CHIP 22K 5% 1/10W
R452 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X202 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
1-688-337-11 DRIVER BOARD
*************
< CAPACITOR >
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
C711 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN701 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-4.7C
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S701 1-762-951-21 SWITCH, PUSH (OUT)
S702 1-762-951-21 SWITCH, PUSH (CHUCK)
************************************************************
A-1106-748-A MAIN BOARD, COMPLETE
(GPZ6: UK/GPZ7: AEP, EE, RU)
A-1107-855-A MAIN BOARD, COMPLETE
(GPZ6: AR/GPZ7: E, E51, MX, AR)
A-1109-912-A MAIN BOARD, COMPLETE (GPZ6: SP, AUS)
A-1109-926-A MAIN BOARD, COMPLETE (GPZ6: KR)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C102 1-124-261-00 ELECT 10uF 20% 50V
C108 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C118 1-124-261-00 ELECT 10uF 20% 50V
C119 1-124-261-00 ELECT 10uF 20% 50V
C128 1-124-261-00 ELECT 10uF 20% 50V
C131 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C134 1-130-495-00 MYLAR 0.1uF 5% 50V
C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C136 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C137 1-126-965-11 ELECT 22uF 20% 50V
C138 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C202 1-124-261-00 ELECT 10uF 20% 50V
C208 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C218 1-124-261-00 ELECT 10uF 20% 50V
C219 1-124-261-00 ELECT 10uF 20% 50V
C228 1-124-261-00 ELECT 10uF 20% 50V
C231 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C234 1-130-495-00 MYLAR 0.1uF 5% 50V
BD DRIVER MAIN
Ver. 1.1
