Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
72
HCD-GPZ6/GPZ7
< DIODE >
D807 6-500-848-01 DIODE MC2840-T112-1
< JUMPER RESISTOR >
FB101 1-216-864-11 SHORT CHIP 0
FB121 1-216-864-11 SHORT CHIP 0
FB201 1-216-864-11 SHORT CHIP 0
FB221 1-216-864-11 SHORT CHIP 0
FB301 1-216-864-11 SHORT CHIP 0
FB321 1-216-864-11 SHORT CHIP 0
< JACK >
J320 1-815-603-11 JACK (MD Link ANALOG IN)
J321 1-815-603-11 JACK (PHONES)
< JUMPER RESISTOR >
JR802 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R132 1-216-841-11 METAL CHIP 47K 5% 1/10W
R133 1-216-821-11 METAL CHIP 1K 5% 1/10W
R232 1-216-841-11 METAL CHIP 47K 5% 1/10W
R233 1-216-821-11 METAL CHIP 1K 5% 1/10W
R839 1-216-821-11 METAL CHIP 1K 5% 1/10W
R840 1-216-821-11 METAL CHIP 1K 5% 1/10W
R841 1-216-821-11 METAL CHIP 1K 5% 1/10W
R842 1-216-821-11 METAL CHIP 1K 5% 1/10W
R843 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R844 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S722 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S723 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S724 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S725 1-762-875-21 SWITCH, KEYBOARD (FM MODE)
S726 1-762-875-21 SWITCH, KEYBOARD (TUNING MODE)
************************************************************
A-1106-399-A POWER BOARD, COMPLETE
(GPZ7: AEP, EE, RU)
A-1107-850-A POWER BOARD, COMPLETE (GPZ7: E, E51)
A-1109-867-A POWER BOARD, COMPLETE (GPZ7: AR)
A-1109-896-A POWER BOARD, COMPLETE (GPZ6: AR, KR)
A-1110-309-A POWER BOARD, COMPLETE (GPZ6: AUS)
A-1110-360-A POWER BOARD, COMPLETE (GPZ6: UK)
A-1121-365-A POWER BOARD, COMPLETE (GPZ7: MX)
A-1127-719-A POWER BOARD, COMPLETE (GPZ6: SP)
*****************************
1-533-233-31 FUSE HOLDER
< CAPACITOR >
C901 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C902 1-126-964-11 ELECT 10uF 20% 50V
C903 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C904 1-126-964-11 ELECT 10uF 20% 50V
C907 1-136-165-00 FILM 0.1uF 5% 50V
C909 1-136-165-00 FILM 0.1uF 5% 50V
C910 1-126-943-11 ELECT 2200uF 20% 25V
C911 1-136-165-00 FILM 0.1uF 5% 50V
C912 1-136-165-00 FILM 0.1uF 5% 50V
C916 1-126-944-11 ELECT 3300uF 20% 25V
C921 1-126-963-11 ELECT 4.7uF 20% 50V
C922 1-126-965-11 ELECT 22uF 20% 50V
< CONNECTOR >
* CN902 1-564-525-11 PLUG, CONNECTOR 10P
< DIODE >
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
D905 8-719-063-79 DIODE 1N4002B
D906 8-719-063-79 DIODE 1N4002B
D907 8-719-063-79 DIODE 1N4002B
D908 8-719-063-79 DIODE 1N4002B
D909 8-719-063-79 DIODE 1N4002B
D910 8-719-063-79 DIODE 1N4002B
D916 8-719-000-08 DIODE MC2838
D917 8-719-083-87 DIODE UDZSTE-1733B
D918 8-719-069-54 DIODE UDZSTE-175.1B
D919 8-719-988-61 DIODE 1SS355TE-17
< TRANSISTOR >
Q901 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q902 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q903 8-729-027-26 TRANSISTOR DTA114YKA-T146
< RESISTOR >
R901 1-216-821-11 METAL CHIP 1K 5% 1/10W
R902 1-216-821-11 METAL CHIP 1K 5% 1/10W
R903 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R905 1-216-841-11 METAL CHIP 47K 5% 1/10W
R906 1-216-833-11 METAL CHIP 10K 5% 1/10W
R907 1-216-845-11 METAL CHIP 100K 5% 1/10W
R908 1-216-837-11 METAL CHIP 22K 5% 1/10W
R909 1-216-833-11 METAL CHIP 10K 5% 1/10W
R910 1-216-809-11 METAL CHIP 100 5% 1/10W
R911 1-216-809-11 METAL CHIP 100 5% 1/10W
R912 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R913 1-208-737-51 FUSIBLE 2.2 5% 1/4W F
0 R914 1-219-591-11 FUSIBLE 0.1 5% 1/2W F
(GPZ6: UK/GPZ7)
0 R914 1-243-634-91 FUSIBLE 0.22 5% 1/2W
(GPZ6: SP, AR, KR, AUS)
0 R915 1-219-121-11 FUSIBLE 0.22 5% 1/4W F
************************************************************
PANEL (2) POWER
