NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• Abbreviation
MX : Mexican model
SA : South African model
AED : North European model
G : German model
AUS : Australian model
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
48
SECTION 9
ELECTRICAL PARTS LIST
A-4426-701-A AMP BOARD, COMPLETE
********************
* 1-533-213-31 HOLDER, FUSE
< CAPACITOR >
C501 1-161-494-00 CERAMIC 0.022uF 25V
C502 1-161-494-00 CERAMIC 0.022uF 25V
C503 1-126-943-11 ELECT 2200uF 20% 25V
C504 1-126-934-11 ELECT 220uF 20% 16V
C505 1-161-494-00 CERAMIC 0.022uF 25V
C506 1-161-494-00 CERAMIC 0.022uF 25V
C507 1-126-935-11 ELECT 470uF 20% 16V
C508 1-104-665-11 ELECT 100uF 20% 10V
C509 1-161-494-00 CERAMIC 0.022uF 25V
C510 1-161-494-00 CERAMIC 0.022uF 25V
C511 1-126-925-11 ELECT 470uF 20% 10V
C512 1-161-494-00 CERAMIC 0.022uF 25V
C513 1-161-494-00 CERAMIC 0.022uF 25V
C514 1-126-960-11 ELECT 1uF 20% 50V
C515 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C516 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C517 1-109-953-11 ELECT 2.2uF 20% 50V
C518 1-109-953-11 ELECT 2.2uF 20% 50V
C519 1-162-207-31 CERAMIC 22PF 5% 50V
C520 1-162-207-31 CERAMIC 22PF 5% 50V
C521 1-137-399-11 FILM 0.1uF 5% 100V
C522 1-137-399-11 FILM 0.1uF 5% 100V
C523 1-126-966-11 ELECT 33uF 20% 16V
C524 1-126-966-11 ELECT 33uF 20% 16V
C525 1-161-494-00 CERAMIC 0.022uF 25V
C526 1-161-494-00 CERAMIC 0.022uF 25V
C527 1-126-961-11 ELECT 2.2uF 20% 50V
C528 1-126-964-11 ELECT 10uF 20% 50V
C529 1-126-964-11 ELECT 10uF 20% 50V
C530 1-128-582-11 ELECT 10uF 20% 63V
C531 1-128-582-11 ELECT 10uF 20% 63V
C532 1-128-551-11 ELECT 22uF 20% 25V
C593 1-162-282-31 CERAMIC 100PF 10% 50V
C594 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
* CN501 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D501 8-719-031-85 DIODE 1N4002L
D502 8-719-031-85 DIODE 1N4002L
D503 8-719-031-85 DIODE 1N4002L
D504 8-719-031-85 DIODE 1N4002L
D505 8-719-031-85 DIODE 1N4002L
D506 8-719-010-76 DIODE UZ-13BS
D507 8-719-110-08 DIODE UZ-8.2BS
D508 8-719-991-33 DIODE 1SS133T-77
D509 8-719-991-33 DIODE 1SS133T-77
D510 8-719-991-33 DIODE 1SS133T-77
D511 8-719-991-33 DIODE 1SS133T-77
< FUSE >
! F501 1-532-388-31 FUSE, TIME LAG 2A 250V
(GRX40AV:AUS,SA/RXD6AV)
! F501 1-576-104-11 FUSE 2A/250V (GRX40AV:MX)
< IC >
IC501 8-749-015-44 IC STK407-070E
< TRANSISTOR >
Q501 8-729-822-89 TRANSISTOR 2SD1667
Q502 8-729-188-23 TRANSISTOR 2SD882-P
Q503 8-729-184-53 TRANSISTOR 2SC1841-EA
Q504 8-729-184-53 TRANSISTOR 2SC1841-EA
Q505 8-729-140-82 TRANSISTOR 2SA988-EA
< RESISTOR >
R501 1-249-401-11 CARBON 47 5% 1/4W F
R502 1-249-399-11 CARBON 33 5% 1/4W F
R503 1-247-855-11 CARBON 10K 5% 1/4W
R504 1-247-863-11 CARBON 22K 5% 1/4W
R505 1-247-855-11 CARBON 10K 5% 1/4W
R506 1-249-438-11 CARBON 56K 5% 1/4W
R507 1-249-438-11 CARBON 56K 5% 1/4W
R508 1-249-420-11 CARBON 1.8K 5% 1/4W F
R509 1-249-420-11 CARBON 1.8K 5% 1/4W F
R510 1-249-438-11 CARBON 56K 5% 1/4W
R511 1-249-438-11 CARBON 56K 5% 1/4W
R512 1-260-072-11 CARBON 4.7 5% 1/2W
R513 1-260-072-11 CARBON 4.7 5% 1/2W
R514 1-247-879-11 CARBON 100K 5% 1/4W
R515 1-247-879-11 CARBON 100K 5% 1/4W
R516 1-249-417-11 CARBON 1K 5% 1/4W F
R517 1-249-417-11 CARBON 1K 5% 1/4W F
R518 1-249-431-11 CARBON 15K 5% 1/4W
R519 1-249-431-11 CARBON 15K 5% 1/4W
R520 1-220-755-11 METAL 0.22 10% 2W
R521 1-220-755-11 METAL 0.22 10% 2W
R522 1-249-430-11 CARBON 12K 5% 1/4W
R523 1-247-839-11 CARBON 2.2K 5% 1/4W
R524 1-249-430-11 CARBON 12K 5% 1/4W
R534 1-247-862-11 CARBON 20K 5% 1/4W
