Sony HCD-MDX10 - Compact Disk Deck Receiver Component - Page 100

– 136 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S631 1-762-875-21 SWITCH, KEYBOARD (MENU/NO)
S632 1-762-875-21 SWITCH, KEYBOARD (- 0)
S633 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S634 1-762-875-21 SWITCH, KEYBOARD (CD FLASH)
S635 1-762-875-21 SWITCH, KEYBOARD (CLEAR)
S636 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S637 1-762-875-21 SWITCH, KEYBOARD (9 TAPE A)
S638 1-762-875-21 SWITCH, KEYBOARD (( TAPE A)
S639 1-762-875-21 SWITCH, KEYBOARD (GEQ CONTROL)
S640 1-762-875-21 SWITCH, KEYBOARD (FILE SELECT)
S641 1-762-875-21 SWITCH, KEYBOARD (EFFECT)
S642 1-762-875-21 SWITCH, KEYBOARD
(EDIT/DIRECTION/TUNER MEMORY)
S643 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/DOLBY NR/PTY)
S644 1-762-875-21 SWITCH, KEYBOARD (REPEAT STEREO/MONO)
S645 1-762-875-21 SWITCH, KEYBOARD (DEMO)
S646 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S647 1-762-875-21 SWITCH, KEYBOARD (CLOCK/TIMER SET)
S648 1-762-875-21 SWITCH, KEYBOARD (CD LOOP)
< VIBRATOR >
X601 1-579-352-11 VIBRATOR, CERAMIC (12.5MHz)
**************************************************************
1-673-379-11 JOG BOARD
**********
< SWITCH >
S601 1-473-534-11 ENCODER, ROTARY (JOG = x +)
**************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
CN1001 1-784-459-11 CONNECTOR, FFC/FPC 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
< HOLDER >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-205-11 SWITCH, LEAF (A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-205-11 SWITCH, LEAF (B 120/70)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
**************************************************************
A-4405-868-A MAIN BOARD, COMPLETE (AEP,UK,G,CIS)
********************
A-4405-869-A MAIN BOARD, COMPLETE (SP,MY,HK)
********************
A-4405-871-A MAIN BOARD, COMPLETE (E,AR)
********************
A-4405-872-A MAIN BOARD, COMPLETE (AUS)
********************
A-4405-873-A MAIN BOARD, COMPLETE (KR)
********************
A-4405-875-A MAIN BOARD, COMPLETE (US,CND)
********************
7-685-872-09 SCREW +BVTT 3X8 (S)
< BATTERY >
BT921 1-528-887-11 BATTERY, LITHIUM SECONDARY
< CAPACITOR >
C101 1-162-286-31 CERAMIC 220PF 10% 50V
C104 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,UK,G,CIS)
C111 1-137-195-11 FILM 0.56uF 5% 50V
C112 1-136-158-00 FILM 0.027uF 5% 50V
C113 1-136-167-00 FILM 0.15uF 5% 50V
C114 1-137-437-11 FILM 0.0056uF 5% 50V
C115 1-136-159-00 FILM 0.033uF 5% 50V
C116 1-137-365-11 FILM 0.0015uF 5% 50V
MAIN
LEAF SW
DISPLAY
JOG
