– 138 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
C556 1-136-165-00 FILM 0.1uF 5% 50V
C557 1-104-665-11 ELECT 100uF 20% 10V
C558 1-164-159-11 CERAMIC 0.1uF 50V
C559 1-104-665-11 ELECT 100uF 20% 10V
C801 1-126-163-11 ELECT 4.7uF 20% 50V
C802 1-162-294-31 CERAMIC 0.001uF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-052-11 ELECT 100uF 20% 10V
C806 1-164-159-11 CERAMIC 0.1uF 50V
C807 1-164-159-11 CERAMIC 0.1uF 50V
C808 1-164-159-11 CERAMIC 0.1uF 50V
C809 1-128-563-11 ELECT 100uF 20% 100V
(E,SP,MY,HK,AR,KR,AUS)
C809 1-128-576-11 ELECT 100uF 20% 63V
(US,CND,AEP,UK,G,CIS)
C810 1-128-562-11 ELECT 47uF 20% 100V
C811 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP,UK,G,CIS)
C812 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP,UK,G,CIS)
C813 1-126-967-11 ELECT 47uF 20% 50V
C841 1-126-974-11 ELECT 3300uF 20% 50V
(E,SP,MY,HK,AR,KR,AUS)
C842 1-127-752-11 ELECT 3300uF 20% 63V
(US,CND,AEP,UK,G,CIS)
C842 1-127-753-11 ELECT 3300uF 20% 71V
(SP,MY,HK,KR,AUS)
C842 1-127-813-11 ELECT 3300uF 20% 71V
(E,AR)
C843 1-136-165-00 FILM 0.1uF 5% 50V
(E,SP,MY,HK,AR,KR,AUS)
C844 1-136-165-00 FILM 0.1uF 5% 50V
C851 1-126-163-11 ELECT 4.7uF 20% 50V
C852 1-162-294-31 CERAMIC 0.001uF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-052-11 ELECT 100uF 20% 10V
C856 1-164-159-11 CERAMIC 0.1uF 50V
C857 1-164-159-11 CERAMIC 0.1uF 50V
C858 1-164-159-11 CERAMIC 0.1uF 50V
C859 1-128-563-11 ELECT 100uF 20% 100V
(E,SP,MY,HK,AR,KR,AUS)
C859 1-128-576-11 ELECT 100uF 20% 63V
(US,CND,AEP,UK,G,CIS)
C891 1-126-974-11 ELECT 3300uF 20% 50V
(E,SP,MY,HK,AR,KR,AUS)
C892 1-127-752-11 ELECT 3300uF 20% 63V
(US,CND,AEP,UK,G,CIS)
C892 1-127-813-11 ELECT 3300uF 20% 71V
(E,SP,MY,HK,AR,KR,AUS)
C893 1-136-165-00 FILM 0.1uF 5% 50V
(E,SP,MY,HK,AR,KR,AUS)
C894 1-136-165-00 FILM 0.1uF 5% 50V
C901 1-136-165-00 FILM 0.1uF 5% 50V
C902 1-111-235-61 ELECT 10000uF 20% 25V
C903 1-104-666-11 ELECT 220uF 20% 25V
C904 1-104-664-11 ELECT 47uF 20% 16V
C905 1-104-661-91 ELECT 330uF 20% 16V
C906 1-136-165-00 FILM 0.1uF 5% 50V
C907 1-126-955-11 ELECT 4700uF 20% 35V
C908 1-126-934-11 ELECT 220uF 20% 10V
C909 1-126-960-11 ELECT 1uF 20% 50V
C910 1-104-665-11 ELECT 100uF 20% 10V
C911 1-126-960-11 ELECT 1uF 20% 50V
C912 1-126-767-11 ELECT 1000uF 20% 16V
C913 1-126-960-11 ELECT 1uF 20% 50V
C914 1-126-767-11 ELECT 1000uF 20% 16V
C915 1-104-664-11 ELECT 47uF 20% 16V
C916 1-164-159-11 CERAMIC 0.1uF 50V
C917 1-126-933-11 ELECT 100uF 20% 16V
C919 1-126-960-11 ELECT 1uF 20% 50V
C920 1-126-934-11 ELECT 220uF 20% 10V
C922 1-126-960-11 ELECT 1uF 20% 50V
C923 1-126-934-11 ELECT 220uF 20% 10V
C924 1-104-665-11 ELECT 100uF 20% 10V
C925 1-104-665-11 ELECT 100uF 20% 10V
C951 1-136-165-00 FILM 0.1uF 5% 50V
C952 1-126-943-11 ELECT 2200uF 20% 25V
C953 1-104-666-11 ELECT 220uF 20% 25V
C955 1-104-661-91 ELECT 330uF 20% 16V
C956 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN102 1-568-443-11 SOCKET, CONNECTOR 13P
(US,CND,E,AR,KR,AUS)
CN102 1-569-321-11 SOCKET, CONNECTOR 15P
(AEP,UK,G,CIS,SP,MY,HK)
* CN103 1-568-946-11 PIN, CONNECTOR 8P
* CN104 1-568-947-11 PIN, CONNECTOR 9P
CN105 1-569-308-11 SOCKET, CONNECTOR (L TYRE) 19P
CN106 1-569-321-11 SOCKET, CONNECTOR 15P
CN107 1-568-440-11 SOCKET, CONNECTOR 17P
CN201 1-568-742-11 SOCKET, CONNECTOR 23P
* CN301 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
* CN302 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
CN371 1-568-741-11 SOCKET, CONNECTOR 23P
CN921 1-568-683-11 PIN, CONNECTOR (PC BAORD) 2P
< DIODE >
D141 8-719-911-19 DIODE 1SS119-25
D191 8-719-911-19 DIODE 1SS119-25
D331 8-719-911-19 DIODE 1SS119-25
D333 8-719-911-19 DIODE 1SS119-25
D334 8-719-911-19 DIODE 1SS119-25
D335 8-719-911-19 DIODE 1SS119-25
D371 8-719-024-99 DIODE 11ES2-NTA2B
D372 8-719-024-99 DIODE 11ES2-NTA2B
D373 8-719-024-99 DIODE 11ES2-NTA2B
D401 8-719-911-19 DIODE 1SS119-25
D411 8-719-911-19 DIODE 1SS119-25
D501 8-719-911-19 DIODE 1SS119-25
D502 8-719-911-19 DIODE 1SS119-25
D503 8-719-911-19 DIODE 1SS119-25
D504 8-719-911-19 DIODE 1SS119-25
D505 8-719-911-19 DIODE 1SS119-25
D506 8-719-911-19 DIODE 1SS119-25
D507 8-719-911-19 DIODE 1SS119-25
D508 8-719-911-19 DIODE 1SS119-25
D509 8-719-911-19 DIODE 1SS119-25
