– 141 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R367 1-249-441-11 CARBON 100K 5% 1/4W
R375 1-249-433-11 CARBON 22K 5% 1/4W
R376 1-249-429-11 CARBON 10K 5% 1/4W
R377 1-249-441-11 CARBON 100K 5% 1/4W
R381 1-249-413-11 CARBON 470 5% 1/4W F
R382 1-249-413-11 CARBON 470 5% 1/4W F
R383 1-249-413-11 CARBON 470 5% 1/4W F
R384 1-247-807-31 CARBON 100 5% 1/4W
R391 1-247-807-31 CARBON 100 5% 1/4W
R392 1-247-807-31 CARBON 100 5% 1/4W
R393 1-249-435-11 CARBON 33K 5% 1/4W
R394 1-249-435-11 CARBON 33K 5% 1/4W
R401 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK,G,CIS)
R402 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK,G,CIS)
! R411 1-215-892-11 METAL OXIDE 1K 5% 2W F
(US)
! R411 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(E,SP,MY,HK,AR,KR,AUS)
! R411 1-216-456-00 METAL OXIDE 820 5% 2W F
(CND)
! R411 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(AEP,UK,G,CIS)
R412 1-249-417-11 CARBON 1K 5% 1/4W F
R413 1-249-417-11 CARBON 1K 5% 1/4W F
R414 1-249-417-11 CARBON 1K 5% 1/4W F
R415 1-249-429-11 CARBON 10K 5% 1/4W
R416 1-249-437-11 CARBON 47K 5% 1/4W
R417 1-249-402-11 CARBON 56 5% 1/4W F
R418 1-249-402-11 CARBON 56 5% 1/4W F
R421 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R421 1-260-091-11 CARBON 220 5% 1/2W
(US,CND,AEP,UK,G,CIS)
R422 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R422 1-260-091-11 CARBON 220 5% 1/2W
(US,CND,AEP,UK,G,CIS)
R423 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R423 1-260-091-11 CARBON 220 5% 1/2W
(US,CND,AEP,UK,G,CIS)
R424 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-247-903-00 CARBON 1M 5% 1/4W
R435 1-249-425-11 CARBON 4.7K 5% 1/4W F
R437 1-249-429-11 CARBON 10K 5% 1/4W
R438 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R440 1-249-433-11 CARBON 22K 5% 1/4W
R441 1-249-435-11 CARBON 33K 5% 1/4W
R443 1-249-417-11 CARBON 1K 5% 1/4W F
R451 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK,G,CIS)
R452 1-260-076-11 CARBON 10 5% 1/2W
(AEP,UK,G,CIS)
R471 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R471 1-260-091-11 CARBON 220 5% 1/2W
(US,CND,AEP,UK,G,CIS)
R472 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R472 1-260-091-11 CARBON 220 5% 1/2W
(US,CND,AEP,UK,G,CIS)
R473 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R473 1-260-091-11 CARBON 220 5% 1/2W
(US,CND,AEP,UK,G,CIS)
R474 1-260-090-11 CARBON 180 5% 1/2W
(E,SP,MY,HK,AR,KR,AUS)
R501 1-249-413-11 CARBON 470 5% 1/4W F
R502 1-249-425-11 CARBON 4.7K 5% 1/4W F
R503 1-249-437-11 CARBON 47K 5% 1/4W
R504 1-249-437-11 CARBON 47K 5% 1/4W
R505 1-249-429-11 CARBON 10K 5% 1/4W
R508 1-249-421-11 CARBON 2.2K 5% 1/4W F
R509 1-249-441-11 CARBON 100K 5% 1/4W
R510 1-247-807-31 CARBON 100 5% 1/4W
R527 1-249-429-11 CARBON 10K 5% 1/4W
R533 1-249-411-11 CARBON 330 5% 1/4W
(KR,AUS)
R536 1-249-429-11 CARBON 10K 5% 1/4W
R543 1-247-807-31 CARBON 100 5% 1/4W
R544 1-247-807-31 CARBON 100 5% 1/4W
R545 1-247-807-31 CARBON 100 5% 1/4W
R546 1-247-807-31 CARBON 100 5% 1/4W
R547 1-247-807-31 CARBON 100 5% 1/4W
R548 1-247-807-31 CARBON 100 5% 1/4W
R549 1-247-807-31 CARBON 100 5% 1/4W
R550 1-247-807-31 CARBON 100 5% 1/4W
R551 1-249-425-11 CARBON 4.7K 5% 1/4W
R552 1-249-425-11 CARBON 4.7K 5% 1/4W
R553 1-249-415-11 CARBON 680 5% 1/4W F
(AEP,UK,G,CIS)
R553 1-249-421-11 CARBON 2.2K 5% 1/4W
(E,AR)
R554 1-249-425-11 CARBON 4.7K 5% 1/4W
(AEP,UK,G,CIS,E,AR,KR,AUS)
R555 1-247-807-31 CARBON 100 5% 1/4W
R556 1-247-807-31 CARBON 100 5% 1/4W
R557 1-247-807-31 CARBON 100 5% 1/4W
R558 1-247-807-31 CARBON 100 5% 1/4W
R559 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK,G,CIS)
R560 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK,G,CIS)
R561 1-247-807-31 CARBON 100 5% 1/4W
R562 1-247-807-31 CARBON 100 5% 1/4W
R563 1-247-807-31 CARBON 100 5% 1/4W
R564 1-247-807-31 CARBON 100 5% 1/4W
R565 1-249-413-11 CARBON 470 5% 1/4W F
R566 1-247-807-31 CARBON 100 5% 1/4W
R567 1-249-417-11 CARBON 1K 5% 1/4W F
R568 1-249-425-11 CARBON 4.7K 5% 1/4W F
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
