– 15 –
This section is extracted from
instruction manual.
LOCATION OF PARTS AND CONTROLS
1 1/u (POWER) button and indicator
2 REC button and indicator
3 REC IT button
4 CD-MD SYNC button
5 DISC SKIP/EX-CHANGE button
6 DISC 1 button and indicator
7 DISC 2 button and indicator
8 DISC 3 button and indicator
9 Disk compartment
10 § (Eject) (MD) button
11 MD WALKMAN SYNC button
12 § (Eject) (CD) button
13 MD WALKMAN LINK jack
14 Disc tray
15 SYNC BASS HIGH indicator
16 SYNC BASS LOW indicator
17 p button
18 ^/CD button and indicator
19 ^/MD button and indicator
20 TUNER/BAND button and indicator
21 CD NON-STOP button and indicator
22 KARAOKE PON/MPX button
23 SYNC EQ button
24 SYNC BASS button
25 REC PAUSE/START button and
indicator
26 DBFB button
27 GROOVE button
28 SURROND button
29 HI DUB button
30 CD-TAPE SYNC button
31 VOLUME knob
32 PHONES jack
33 ENTER/YES button and indicator
34 ) + button and indicator
35 NAME EDIT/CHAR button
36 JOG/0x) dial and
indicator
37 MENU/NO button
38 ) – button and indicator
39 CLEAR button
40 CD FLASH button
41 CD LOOP button
42 MIX MIC jack
43 TIMER SELECT button and indicator
44 CLOCK/TIMER SET button
45 MIC LEVEL knob
46 SPECTRUM ANALYZER button
47 DISPLAY button
48 REPEAT STEREO/MONO button
49 DOLBY NR/PLAY MODE/PTY button
50 DIRECTION/EDIT/TUNER MEMORY
button
51 P FILE MEMORY button
52 GEQ CONTROL button
53 FILE SELECT button
54 EFFECT button
55 FUNCTION button and indicator
56 9/TAPE B button and indicator
57 (/TAPE B button and indicator
58 9/TAPE A button and indicator
59 (/TAPE A button and indicator
60 Remote sensor
61 SYNC EQ indicator
62 EFFECT indicator
63 Display Window
64 POWER SAVE/DEMO (STANDBY)
button
