Sony HCD-MDX10 - Compact Disk Deck Receiver Component - Page 95

– 131 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-078-00 RES,CHIP 16K 5% 1/10W
R172 1-216-073-00 METAL CHIP 10K 5% 1/10W
R173 1-216-077-00 METAL CHIP 15K 5% 1/10W
R181 1-216-078-00 RES,CHIP 16K 5% 1/10W
R182 1-216-073-00 METAL CHIP 10K 5% 1/10W
R183 1-216-077-00 METAL CHIP 15K 5% 1/10W
< NETWORK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
RN102 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT IN SW)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
A-4699-893-A BD (MD) BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-125-822-11 TANTALUM 10uF 20% 10V
C102 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C103 1-125-822-11 TANTALUM 10uF 20% 10V
C104 1-125-822-11 TANTALUM 10uF 20% 10V
C105 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C106 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C107 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C108 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C109 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C111 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C112 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C113 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C115 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C116 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C118 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C119 1-125-822-11 TANTALUM 10uF 20% 10V
C121 1-125-822-11 TANTALUM 10uF 20% 10V
C122 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C123 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C124 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C127 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C128 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C129 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C130 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C131 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C132 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C133 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C134 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C135 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C136 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C142 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C143 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C144 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C146 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C152 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C153 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C156 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C158 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-104-601-11 ELECT CHIP 10uF 20% 10V
C161 1-104-601-11 ELECT CHIP 10uF 20% 10V
C163 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C164 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C167 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C168 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C169 1-125-822-11 TANTALUM 10uF 20% 10V
C171 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C181 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C183 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C184 1-117-970-11 ELECT CHIP 22uF 20% 10V
C185 1-164-611-11 CERAMIC CHIP 0.001uF 10% 500V
C187 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C188 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C189 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C190 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C191 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C196 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C197 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-569-479-21 CONNECTOR, FPC 21P
CN102 1-784-833-21 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN103 1-784-834-21 CONNECTOR,FFC(LIF(NON-ZIF))23P
CN104 1-770-687-11 CONNECTOR, FFC/FPC 4P
CN110 1-695-440-21 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D181 8-719-046-86 DIODE F1J6TP
D183 8-719-046-86 DIODE F1J6TP
< IC >
IC101 8-752-080-95 IC CXA2523AR
IC103 8-729-903-10 IC TRANSISTOR FMW1
IC121 8-752-389-44 IC CXD2654R
IC123 8-759-096-87 IC TC7WU04FU(TE12R)
IC124 8-759-498-44 IC MSM51V4400-70TS-K
IC152 8-759-430-25 IC BH6511FS-E2
IC171 8-759-487-04 IC BR24C02F-E2
IC181 8-759-481-17 IC MC74ACT08DTR2
IC192 8-759-460-72 IC BA033FP-E2
< COIL >
L101 1-414-813-11 FERRITE 0uH
L102 1-414-813-11 FERRITE 0uH
L103 1-414-813-11 FERRITE 0uH
L105 1-414-813-11 FERRITE 0uH
L106 1-414-813-11 FERRITE 0uH
BD (MD)
BD (CD)
