– 94 –
Pin Name I/O Function
45 COM-CLK O Common serial clock output
46 CD-POWER O CD power on signal output
47 CD-DATA O CD data output
48 CD-CLK O CD clock output
49 PL-CLK O Clock signal output to pro-logic (Not used)
50 PL-DATA I Data signal output to pro-logic (Not used)
51 M62442-CLK O Clock signal output for IC111 (M62442FP)
52 M62442-DATA O Data signal output for IC111 (M62442FP)
53 LEVEL-CONT-A O Not used
54 LEVEL-CONT-B O Not used
55 IIC-DATA O Data output for IC601
56 IIC-CLK O Clock output for IC601
57 XRST O CD reset signal output
58 XLT O CD latch signal output
59 FCS-SW O Not used
60 TBL-L O
Table motor control output
61 TBL-R O
62 — O Not used
63 LOAD-OUT O
Loading motor control signal output
64 LOAD-IN O
65 ST-CLK O Tuner clock output
66 ST-DIN I Tuner data input
67 ST-DOUT O Tuner data output
68 ST-CE O Tuner chip enable output
69 TUNED I Tuned detection for tuner
70 STEREO I Stereo detection for tuner
71 VSS – Ground
72 ST-MUTE O Tuner mute signal output
73 SENS2 I
BD Condition signal input
74 SENS I
75 DISC-SENS I Slit sensor of disc table input
76 T-SENS I CD table detection signal input
77 CAPM-CNT2P O Capstan motor control 2 (+) signal output
78 ENC 3 I
79 ENC 2 I Disc tray adrress detect encoder input
80 ENC 1 I
81 OUT-OPEN O Loading out detection signal output
82 CAP-M-H/L O Capstan motor H/N speed select signal output
83 B-TRG O Trigger motor control output
84 A-TRG O Trigger motor control output
85 CAPM-CONT1M O Capstan motor control 1 (–) signal output
86 CAPM-CONT2M O Capstan motor control 2 (–) signal output
87 TC-MUTE O TC mute ON/OFF selection output
Pin No.
