– 113 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C921 1-126-964-11 ELECT 10uF 20% 50V
C922 1-126-767-11 ELECT 1000uF 20% 16V
C931 1-126-964-11 ELECT 10uF 20% 50V
C932 1-126-916-11 ELECT 1000uF 20% 6.3V
C933 1-126-925-11 ELECT 470uF 20% 10V
C934 1-126-933-11 ELECT 100uF 20% 10V
C941 1-126-964-11 ELECT 10uF 20% 50V
C942 1-126-933-11 ELECT 100uF 20% 10V
C951 1-126-967-11 ELECT 47uF 20% 10V
C952 1-136-165-00 FILM 0.1uF 5% 50V
C953 1-136-173-00 FILM 0.47uF 5% 50V
C961 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C991 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN101 1-568-832-11 SOCKET, CONNECTOR 13P
CN102 1-784-600-11 SOCKET, CONNECTOR (NON ZIF)15P
(GRX8:E3,SP,MY,HK,TW,EA3/RX88/RX99)
CN102 1-784-601-11 SOCKET, CONNECTOR (NON ZIF) 13P
(GRX8:E2,MX,EA4,TH,AUS/R800)
* CN103 1-568-946-11 PIN, CONNECTOR 8P
* CN104 1-568-947-11 PIN, CONNECTOR 9P
CN105 1-764-698-11 SOCKET, CONNECTOR (NON ZIF) 19P
CN106 1-568-834-11 SOCKET, CONNECTOR 15P
* CN107 1-568-836-11 SOCKET, CONNECTOR 17P
* CN301 1-568-449-11 HOUSING, CONNECTOR(PC BOARD) 3P
CN901 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
CN902 1-770-728-11 CONNECTOR, BOARD TO BOARD 9P
* CN961 1-564-518-11 PLUG, CONNECTOR 3P
< DIODE >
D381 8-719-988-62 DIODE 1SS355
D382 8-719-988-62 DIODE 1SS355
D502 8-719-988-62 DIODE 1SS355
D508 8-719-988-62 DIODE 1SS355
D572 8-719-988-62 DIODE 1SS355
D901 8-719-988-62 DIODE 1SS355
D911 8-719-988-62 DIODE 1SS355
D931 8-719-988-62 DIODE 1SS355
D932 8-719-210-33 DIODE EC10DS2
D951 8-719-988-62 DIODE 1SS355
D952 8-719-988-62 DIODE 1SS355
D953 8-719-988-62 DIODE 1SS355
D954 8-719-988-62 DIODE 1SS355
D955 8-719-210-33 DIODE EC10DS2
D956 8-719-988-62 DIODE 1SS355
< GROUND TERMINAL >
* EPT901 4-870-539-11 PLATE, GROUND
< COIL >
FB381 1-414-234-11 INDUCTOR CHIP 0UH
< IC >
IC111 8-759-495-24 IC M62442FP-TP
IC191 8-759-636-55 IC M5218AFP
IC301 8-759-495-26 IC HA12215
IC391 8-749-923-04 IC TOTX178
IC401 8-759-636-55 IC M5218AFP
IC411 8-759-636-55 IC M5218AFP
IC501 8-759-496-10 IC uPD780018AYGF-011-3BA
IC901 8-759-604-86 IC M5F7807L
IC902 8-759-604-90 IC M5F7907L
IC911 8-759-231-58 IC TA7812S
IC921 8-759-604-38 IC M5F78M10
IC931 8-759-231-53 IC TA7805S
IC941 8-759-604-86 IC M5F7807L
IC951 8-759-635-63 IC M51943BSL
< JACK >
J101 1-774-411-11 JACK, PIN 6P
(VIDEO(AUDIO) IN, MD IN, MD/VIDEO (AUDIO) OUT)
J191 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
< JUMPER RESISTOR >
JR1 1-216-295-91 SHORT 0
JR2 1-216-295-91 SHORT 0
JR4 1-216-295-91 SHORT 0
JR5 1-216-295-91 SHORT 0
< COIL >
L371 1-412-032-11 INDUCTOR CHIP 100uH
(RX88/RX99:AEP,UK,G)
L372 1-412-032-11 INDUCTOR CHIP 100uH
L391 1-412-032-11 INDUCTOR CHIP 100uH
L569 1-412-032-11 INDUCTOR CHIP 100uH
L570 1-412-032-11 INDUCTOR CHIP 100uH
L572 1-412-032-11 INDUCTOR CHIP 100uH
< FILTER >
FL131 1-233-289-21 FILTER, EMI (SMD)
FL501 1-233-289-21 FILTER, EMI (SMD)
FL502 1-233-289-21 FILTER, EMI (SMD)
< TRANSISTOR >
Q111 8-729-119-78 TRANSISTOR 2SC403SP-51
Q112 8-729-119-78 TRANSISTOR 2SC403SP-51
Q113 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q141 8-729-422-57 TRANSISTOR UN4111
Q142 8-729-900-36 TRANSISTOR DTC124ES
Q143 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q161 8-729-119-78 TRANSISTOR 2SC403SP-51
Q162 8-729-119-78 TRANSISTOR 2SC403SP-51
Q163 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q191 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q331 8-729-118-00 TRANSISTOR 2SB1116-L
Q332 8-729-900-80 TRANSISTOR DTC114ES
Q333 8-729-118-00 TRANSISTOR 2SB1116-L
Q334 8-729-900-80 TRANSISTOR DTC114ES
Q335 8-729-900-80 TRANSISTOR DTC114ES
Q336 8-729-116-55 TRANSISTOR 2SB1068
Q337 8-729-144-44 TRANSISTOR 2SD1513
Q338 8-729-422-57 TRANSISTOR UN4111
Q339 8-729-900-80 TRANSISTOR DTC114ES
MAIN
