– 117 –
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-109-69 DIODE RD3.6ES-B2
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-010-43 DIODE UZ-5.6BSC
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY
************************************************************
* A-4407-257-A PANEL BOARD, COMPLETE
*********************
(GRX8/R800/RX99:EE,CIS)
* A-4407-308-A PANEL BOARD, COMPLETE (RX88)
*********************
* A-4407-720-A PANEL BOARD, COMPLETE (RX99:AEP,UK,G)
*********************
* 4-932-810-31 CUSHION (FL)
* 4-996-796-01 HOLDER, FL TUBE
< CAPACITOR >
C600 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C601 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C602 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C603 1-124-589-11 ELECT 47uF 20% 16V
C604 1-124-259-11 ELECT 4.7uF 20% 50V
C605 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C608 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C609 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C610 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C611 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C612 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C613 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C614 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C615 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C616 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C617 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C618 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C619 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C620 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C621 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C625 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C626 1-124-589-11 ELECT 47uF 20% 16V
C631 1-126-157-11 ELECT 10uF 20% 16V
C632 1-126-157-11 ELECT 10uF 20% 16V
C633 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C634 1-126-157-11 ELECT 10uF 20% 16V
C652 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C801 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C802 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C803 1-124-589-11 ELECT 47uF 20% 16V
C804 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C805 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C806 1-126-963-11 ELECT 4.7uF 20% 50V
C807 1-163-017-00 CERAMIC CHIP 4700PF 10% 50V
C808 1-163-017-00 CERAMIC CHIP 4700PF 10% 50V
C809 1-126-967-11 ELECT 47uF 20% 50V
C851 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C852 1-126-935-11 ELECT 470uF 20% 6.3V
C853 1-126-963-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
* CN601 1-568-832-11 SOCKET, CONNECTOR 13P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MOTOR (TURN)
MOTOR (SLIDE) PANEL
