Sony HCD-SC8 - ELECTRICAL PARTS LIST; < CAPACITOR >; < CONNECTOR >; < DIODE >

103
HCD-SC5/SC6/SC8
SECTION 8
ELECTRICAL PARTS LIST
Note:
• Due to standardization, replacements in the parts
list may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
•Abbreviation
AUS: Australian model
E32 : 110-240V AC area in E model
EA : Saudi Arabia model
HK : Hong Kong model
KR : Korean model
MX : Mexican model
RU : Russian model
SP : Singapore model
TW : Taiwan model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
A-4748-358-A AMP BOARD, COMPLETE
(SC5:AEP,UK,RU,KR,EA/SC6:AEP,UK,RU,KR,AUS)
********************
A-4749-319-A AMP BOARD, COMPLETE (SC8:MX)
********************
A-4749-707-A AMP BOARD, COMPLETE
(SC5:E32,HK,SP/SC6:EA,SP)
********************
A-4749-778-A AMP BOARD, COMPLETE
(SC8:AEP,UK,RU,KR,EA,AUS)
********************
A-4749-789-A AMP BOARD, COMPLETE (SC8:E32,HK,SP)
********************
A-4750-126-A AMP BOARD, COMPLETE (SC8:TW)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C102 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C103 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
(SC5/SC6)
C104 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C105 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C106 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C121 1-126-948-11 ELECT 100uF 20.00% 35V
C122 1-126-948-11 ELECT 100uF 20.00% 35V
C123 1-126-948-11 ELECT 100uF 20.00% 35V
(SC5/SC6)
C124 1-126-948-11 ELECT 100uF 20.00% 35V
C125 1-126-948-11 ELECT 100uF 20.00% 35V
C126 1-126-948-11 ELECT 100uF 20.00% 35V
C131 1-136-157-00 FILM 0.022uF 5% 50V
C132 1-136-157-00 FILM 0.022uF 5% 50V
C133 1-136-157-00 FILM 0.022uF 5% 50V
(SC5/SC6)
C134 1-136-157-00 FILM 0.022uF 5% 50V
C135 1-136-157-00 FILM 0.022uF 5% 50V
C136 1-136-157-00 FILM 0.022uF 5% 50V
C141 1-104-665-11 ELECT 100uF 20.00% 10V
C142 1-104-665-11 ELECT 100uF 20.00% 10V
C143 1-104-665-11 ELECT 100uF 20.00% 10V
(SC5/SC6)
C144 1-104-665-11 ELECT 100uF 20.00% 10V
C145 1-104-665-11 ELECT 100uF 20.00% 10V
C146 1-104-665-11 ELECT 100uF 20.00% 10V
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C151 1-104-665-11 ELECT 100uF 20.00% 10V
C152 1-104-665-11 ELECT 100uF 20.00% 10V
C153 1-104-665-11 ELECT 100uF 20.00% 10V
(SC5/SC6)
C154 1-104-665-11 ELECT 100uF 20.00% 10V
C155 1-104-665-11 ELECT 100uF 20.00% 10V
C156 1-104-665-11 ELECT 100uF 20.00% 10V
C161 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C162 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C163 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(SC5/SC6)
C164 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C165 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C166 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C171 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C172 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C173 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(SC5/SC6)
C174 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C175 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C176 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C181 1-136-157-00 FILM 0.022uF 5% 50V
C182 1-136-157-00 FILM 0.022uF 5% 50V
C183 1-136-157-00 FILM 0.022uF 5% 50V
(SC5/SC6)
C184 1-136-157-00 FILM 0.022uF 5% 50V
C185 1-136-157-00 FILM 0.022uF 5% 50V
C186 1-136-157-00 FILM 0.022uF 5% 50V
C191 1-136-177-00 FILM 1uF 5.00% 50V
C192 1-136-177-00 FILM 1uF 5.00% 50V
C193 1-136-177-00 FILM 1uF 5.00% 50V
(SC5/SC6)
C194 1-136-177-00 FILM 1uF 5.00% 50V
C195 1-136-177-00 FILM 1uF 5.00% 50V
C196 1-136-177-00 FILM 1uF 5.00% 50V
C201 1-136-177-00 FILM 1uF 5.00% 50V
C202 1-136-177-00 FILM 1uF 5.00% 50V
C203 1-136-177-00 FILM 1uF 5.00% 50V
(SC5/SC6)
C204 1-136-177-00 FILM 1uF 5.00% 50V
C205 1-136-177-00 FILM 1uF 5.00% 50V
C206 1-136-177-00 FILM 1uF 5.00% 50V
C211 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C212 1-164-505-11 CERAMIC CHIP 2.2uF 16V
AMP
