Sony HCD-SC8 - 3-2. DDCON and FL Boards; 3-3. Play Button and Slot Disc

11
HCD-SC5/SC6/SC8
4 DDCON board
q; FL board
7 POWER LED board
8 power button sub assy
1 four screws
(DIA. 2.6
× 8)
9 four screws
(DIA. 2.6
× 8)
6 two screws
(DIA. 2.6
× 8)
qf four screws
(DIA. 2.6
× 8)
qa three screws
(DIA. 2.6
× 8)
5 four screws
(DIA. 2.6
× 8)
2 wire (flat type) (CN815)
3 connector
(CN819)
qs panel top (L)
qg panel top (R)
qd band button
qh front (ml) panel
3-2. DDCON BOARD, FL BOARD
1 three screws
(+BVTP 3
× 8)
2 three screws
(+BVTP 3
× 8
)
4 three screws
(+BVTP 3
× 8)
5 two screws
(+BVTP 3
× 8)
3 play button
6 slot disc
7 sheet
9 slot disc (inside)
8 cover slot
q; front (al) panel
3-3. PLAY BUTTON, SLOT DISC
