Sony HCD-SC8 - Close Lever; Dir Lever, Gear (Idl-B)

19
HCD-SC5/SC6/SC8
3-17. CLOSE LEVER
1 washer (3-1-0.4)
2 close lever sprin
g
4 shaft disc stop
5 close lever
3 claw
3-18. DIR LEVER, GEAR (IDL-B)
3 gear puley
2 claw
9 DIR lever
5 gear (IDL-A)
q; gear (IDL-B)
1 DIR spring
8 stoper
6 Loosen the screw.
7 Hold the release lever
and change the direction.
4 gear (cap)
