17
HCD-SC5/SC6/SC8
3-13. RF BOARD
5 RF board
2 wire (flat type)
(CN003)
3 wire (flat type)
(CN001)
4 wire (flat type)
(CN002)
1 claw
3-14. OPTICAL PICK-UP (TDP022W)
1 two step screws (M)
2 step screw (M)
3 two insulators
4 insulator
5 optical pick-up
(TDP022W)
