Sony HCD-SC8 - Printed Wiring Board - Rf Section

3737
HCD-SC5/SC6/SC8
6-3. PRINTED WIRING BOARD – RF SECTION – • See page 30 for Circuit Boards Location.
• : Uses unleaded solder.
(SIDE A)
RF BOARD
(SIDE B)
RF BOARD
IC001
TO
DVD BOARD
CN401
(Page 40)
A
E
E
OPTICAL PICK-UP
BLOCK
(TDP022W)
FLEXIBLE BOARD
1-684-822-
11
(11)
1-684-822-
11
(11)
1
16
17 32
48
33
64 49
1 2 3 4 5 6 7 8 9 10 11 12 13
A
B
C
D
E
F
Ref. No. Location
D001 B-3
D002 B-3
IC001 D-11
Q001 C-11
Q002 B-11
• Semiconductor
Location
