107
HCD-SC5/SC6/SC8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-4748-364-A DDCON BOARD, COMPLETE
**********************
< CAPACITOR >
C820 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C821 1-126-176-11 ELECT 220uF 20% 10V
C822 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C823 1-126-967-11 ELECT 47uF 20.00% 50V
C826 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN814 1-779-552-21 CONNECTOR,FFC(LIF(NON-ZIF))15P
CN815 1-779-281-11 CONNECTOR,FFC(LIF(NON-ZIF))13P
* CN819 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D806 8-719-404-50 DIODE MA111-TX
D807 8-719-404-50 DIODE MA111-TX
D808 8-719-404-50 DIODE MA111-TX
D809 8-719-404-50 DIODE MA111-TX
D810 8-719-069-56 DIODE UDZSTE-176.2B
< FERRITE BEAD >
FB800 1-414-813-11 FERRITE 0uH
FB801 1-414-813-11 FERRITE 0uH
FB802 1-414-813-11 FERRITE 0uH
< COIL >
L801 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q803 8-729-808-42 TRANSISTOR 2SD1624T-TD-E
Q804 8-729-808-42 TRANSISTOR 2SD1624T-TD-E
< RESISTOR >
R800 1-216-819-11 METAL CHIP 680 5% 1/16W
R801 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R802 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R809 1-216-821-11 METAL CHIP 1K 5% 1/16W
R826 1-216-795-11 METAL CHIP 6.8 5% 1/10W
R827 1-216-795-11 METAL CHIP 6.8 5% 1/10W
R828 1-216-795-11 METAL CHIP 6.8 5% 1/10W
R836 1-216-817-11 METAL CHIP 470 5% 1/16W
R838 1-216-805-11 METAL CHIP 47 5% 1/16W
R841 1-216-809-11 METAL CHIP 100 5% 1/16W
R842 1-216-809-11 METAL CHIP 100 5% 1/16W
R843 1-216-809-11 METAL CHIP 100 5% 1/16W
R845 1-216-819-11 METAL CHIP 680 5% 1/16W
R846 1-216-821-11 METAL CHIP 1K 5% 1/16W
R849 1-216-813-11 METAL CHIP 220 5% 1/16W
R850 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R855 1-216-809-11 METAL CHIP 100 5% 1/16W
R860 1-216-815-11 METAL CHIP 330 5% 1/16W
R864 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R874 1-216-839-11 METAL CHIP 33K 5% 1/16W
< SWITCH >
S801 1-786-220-11 SWITCH, KEY BOARD (NEXT >)
S802 1-786-220-11 SWITCH, KEY BOARD (. PREV)
S803 1-786-220-11 SWITCH, KEY BOARD (H)
S804 1-786-220-11 SWITCH, KEY BOARD (X)
S805 1-786-220-11 SWITCH, KEY BOARD (x)
S806 1-786-220-11 SWITCH, KEY BOARD (-(VOLUME))
S807 1-786-220-11 SWITCH, KEY BOARD (+(VOLUME))
S808 1-786-220-11 SWITCH, KEY BOARD (BASS LEVEL)
S809 1-786-220-11 SWITCH, KEY BOARD (A)
< TRANSFORMER >
T801 1-437-416-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
1-688-337-11 DRIVER BOARD
*************
< CAPACITOR >
C705 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C711 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN701 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE)7P
< DIODE >
D701 8-719-921-40 DIODE MTZJ-T-77-4.7C
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-415-11 CARBON 680 5% 1/4W F
R702 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S701 1-762-951-13 SWITCH, PUSH
S702 1-762-951-13 SWITCH, PUSH
S703 1-762-951-13 SWITCH, PUSH
************************************************************
A-4748-350-A DVD BOARD, COMPLETE (SC5:AEP,UK)
********************
A-4749-315-A DVD BOARD, COMPLETE (SC8:MX)
********************
A-4749-579-A DVD BOARD, COMPLETE (SC6:AEP,UK)
********************
A-4749-584-A DVD BOARD, COMPLETE (SC8:AEP,UK)
********************
A-4749-709-A DVD BOARD, COMPLETE (SC5:HK,SP)
********************
A-4749-716-A DVD BOARD, COMPLETE (SC5:E32)
********************
A-4749-749-A DVD BOARD, COMPLETE (SC5:RU)
********************
A-4749-756-A DVD BOARD, COMPLETE (SC6:AUS)
********************
A-4749-758-A DVD BOARD, COMPLETE (SC6:RU)
********************
A-4749-760-A DVD BOARD, COMPLETE (SC6:SP)
********************
A-4749-762-A DVD BOARD, COMPLETE (SC5:EA)
********************
DRIVER DVDDDCON
