124
HCD-SC5/SC6/SC8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R022 1-216-813-11 METAL CHIP 220 5% 1/10W
R023 1-216-820-11 METAL CHIP 820 5% 1/10W
R024 1-216-864-11 METAL CHIP 0 5% 1/10W
R025 1-216-809-11 METAL CHIP 100 5% 1/10W
R026 1-218-718-11 METAL CHIP 12K 0.5% 1/16W
R027 1-216-864-11 METAL CHIP 0 5% 1/10W
R028 1-216-864-11 METAL CHIP 0 5% 1/10W
R029 1-216-864-11 METAL CHIP 0 5% 1/10W
R032 1-216-809-11 METAL CHIP 100 5% 1/10W
R033 1-216-864-11 METAL CHIP 0 5% 1/10W
R034 1-219-570-11 RES-CHIP 10M 5% 1/10W
R035 1-216-864-11 METAL CHIP 0 5% 1/10W
R041 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
1-689-360-11 SCART BOARD (AEP,UK,RU)
************
< CAPACITOR >
C130 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK,RU)
C131 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK,RU)
< FERRITE BEAD >
FB101 1-469-324-21 FERRITE 0uH (AEP,UK,RU)
FB102 1-469-324-21 FERRITE 0uH (AEP,UK,RU)
FB103 1-469-324-21 FERRITE 0uH (AEP,UK,RU)
FB104 1-469-324-21 FERRITE 0uH (AEP,UK,RU)
< JACK >
J101 1-815-911-11 CONNECTOR, SQUARE TYPE 21P (EURO AV)
(AEP,UK,RU)
************************************************************
RF SCART
Ref. No. Part No. Description Remarks
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MISCELLANEOUS
**************
67 1-827-619-11 FLEXIBLE FLAT CABLE (13 CORE)
101 1-468-790-11 POWER SWITCHING (including Ref.No.201)
(SC6:AEP,UK/SC8:AEP,UK)
152 1-500-657-11 CORE, FERRIET
0 154 1-696-169-51 CORD, POWER (EXCEPT AUS,KR,MX,TW)
0 154 1-696-848-51 CORD, POWER (AUS)
0 154 1-769-079-22 CORD, POWER (KR)
0 154 1-775-789-91 CORD, POWER (MX,TW)
156 1-763-861-12 FAN, DC
157 1-469-854-11 CORE, FERRITE
159 1-827-625-11 FLEXIBLE FLAT CABLE (11 CORE)
160 1-827-620-11 FLEXIBLE FLAT CABLE (15 CORE)
161 1-827-623-11 FLEXIBLE FLAT CABLE (15 CORE)
162 1-827-624-11 FLEXIBLE FLAT CABLE (11 CORE)
163 1-827-622-11 FLEXIBLE FLAT CABLE (15 CORE)
164 1-827-621-11 FLEXIBLE FLAT CABLE (29 CORE)
201 1-468-790-11 POWER SWITCHING (including Ref.No.101)
(SC6:AEP,UK/SC8:AEP,UK)
205 1-827-626-11 FLEXIBLE FLAT CABLE (29 CORE)
602 1-685-250-11 PWB, FLEXIBLE
0 605 1-477-263-11 OPTICAL PICK-UP (TDP022W)
0 F901 1-532-465-31 FUSE (T3.15AL/250V)
(SC5:TW/SC6:AEP,UK/SC8:AEP,UK,MX,TW)
0 F901 1-533-453-12 FUSE, GLASS TUBE (DIA. 5) (T5AL/125V)
(SC5:TW/SC8:MX,TW)
0 F902 1-532-465-31 FUSE (T3.15AL/250V)
(SC6:AEP,UK/SC8:AEP,UK)
FL801 1-518-924-11 INDICATOR TUBE, FLUORESCENT
M701 X-4955-496-1 MOTOR (PULLEY) ASSY (LOADING)
