68
HCD-SHAKE5/SHAKE6D
SECTION 8
ELECTRICAL PARTS LIST
0 A-1938-478-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C3000 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C3001 1-114-326-11 CERAMIC CHIP 0.22uF 10% 25V
C3002 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C3003 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3004 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3005 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3006 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3007 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C3009 1-126-965-91 ELECT 22uF 20% 50V
C3011 1-118-310-11 CERAMIC CHIP 0.022uF 10% 100V
C3012 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C3013 1-112-723-21 CERAMIC CHIP 0.0047uF 10% 250V
C3016 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C3017 1-126-933-11 ELECT 100uF 20% 16V
C3019 1-126-933-11 ELECT 100uF 20% 16V
C3020 1-126-965-91 ELECT 22uF 20% 50V
C3021 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C3022 1-118-310-11 CERAMIC CHIP 0.022uF 10% 100V
C3025 1-114-326-11 CERAMIC CHIP 0.22uF 10% 25V
< CONNECTOR >
CN3001 1-779-556-21 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
< DIODE >
D3000 6-503-720-11 DI IL0353W61B3MKE01
D3001 6-502-970-01 DI DZ2J068M0L
D3002 6-503-987-01 DI RF05VAM2STR
D3003 6-503-987-01 DI RF05VAM2STR
D3004 6-503-987-01 DI RF05VAM2STR
D3005 6-503-987-01 DI RF05VAM2STR
< JUMPER RESISTOR >
JR3003 1-216-296-11 SHORT CHIP 0
JR3004 1-216-296-11 SHORT CHIP 0
JR3010 1-216-296-11 SHORT CHIP 0
JR3012 1-216-296-11 SHORT CHIP 0
JR3014 1-216-296-11 SHORT CHIP 0
JR3015 1-216-296-11 SHORT CHIP 0
JR3016 1-216-296-11 SHORT CHIP 0
JR3017 1-216-864-11 SHORT CHIP 0
JR3018 1-216-296-11 SHORT CHIP 0
JR3021 1-216-864-11 SHORT CHIP 0
JR3022 1-216-296-11 SHORT CHIP 0
JR3023 1-216-296-11 SHORT CHIP 0
JR3024 1-216-296-11 SHORT CHIP 0
JR3025 1-216-296-11 SHORT CHIP 0
JR3026 1-216-296-11 SHORT CHIP 0
JR3027 1-216-296-11 SHORT CHIP 0
JR3028 1-216-296-11 SHORT CHIP 0
JR3029 1-216-296-11 SHORT CHIP 0
JR3030 1-216-296-11 SHORT CHIP 0
JR3031 1-216-296-11 SHORT CHIP 0
JR3032 1-216-864-11 SHORT CHIP 0
JR3033 1-216-296-11 SHORT CHIP 0
JR3035 1-216-296-11 SHORT CHIP 0
JR3036 1-216-296-11 SHORT CHIP 0
JR3037 1-216-296-11 SHORT CHIP 0
JR3038 1-216-296-11 SHORT CHIP 0
JR3039 1-216-296-11 SHORT CHIP 0
JR3040 1-216-296-11 SHORT CHIP 0
JR3041 1-216-296-11 SHORT CHIP 0
JR3042 1-216-296-11 SHORT CHIP 0
JR3043 1-216-296-11 SHORT CHIP 0
JR3044 1-216-296-11 SHORT CHIP 0
< COIL >
L3000 1-412-541-21 INDUCTOR 220uH
< FLUORESCENT INDICATOR TUBE >
ND3000 1-483-465-21 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q3000 6-553-083-01 TR PBSS4160T
Q3001 6-553-083-01 TR PBSS4160T
< RESISTOR >
R3000 1-216-797-11 METAL CHIP 10 5% 1/10W
R3001 1-216-809-11 METAL CHIP 100 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
FL
• Abbreviation
AUS : Australian model
E2 : 120 V AC area in E model
E4 : African model
E12 : 220 – 240 V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
RU : Russian model
SAF : South African model
TH : Thai model
