Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SHAKE5/SHAKE6D
82
R1666 1-218-929-11 METAL CHIP 10 5% 1/16W
R1667 1-218-929-11 METAL CHIP 10 5% 1/16W
R1668 1-218-941-81 METAL CHIP 100 5% 1/16W
R1669 1-218-941-81 METAL CHIP 100 5% 1/16W
R1670 1-218-990-81 SHORT CHIP 0
R1671 1-216-864-11 SHORT CHIP 0
R1672 1-218-990-81 SHORT CHIP 0
R1673 1-218-990-81 SHORT CHIP 0
R1674 1-218-933-11 METAL CHIP 22 5% 1/16W
R1675 1-218-929-11 METAL CHIP 10 5% 1/16W
R1676 1-218-929-11 METAL CHIP 10 5% 1/16W
R1677 1-218-929-11 METAL CHIP 10 5% 1/16W
R1678 1-218-953-11 METAL CHIP 1K 5% 1/16W
R1679 1-218-953-11 METAL CHIP 1K 5% 1/16W
R2000 1-218-941-81 METAL CHIP 100 5% 1/16W
R2001 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2002 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2003 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2004 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2005 1-218-941-81 METAL CHIP 100 5% 1/16W
R2006 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2007 1-218-989-11 METAL CHIP 1M 5% 1/16W
R2008 1-218-990-81 SHORT CHIP 0
R2009 1-250-642-11 METAL CHIP 12K 1% 1/10W
R2010 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2011 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2012 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2013 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2014 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R2015 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R2016 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2017 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2018 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2019 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2020 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2021 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2022 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2023 1-218-979-11 METAL CHIP 150K 5% 1/16W
R2025 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2026 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R2027 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2028 1-218-985-11 METAL CHIP 470K 5% 1/16W
R2029 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R2030 1-218-985-11 METAL CHIP 470K 5% 1/16W
R2031 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R2032 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3014 1-216-864-11 SHORT CHIP 0
R3015 1-250-614-11 METAL CHIP 820 1% 1/10W
R3016 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3017 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3018 1-218-977-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB26 1-234-372-11 RES, NETWORK 100 (1005X4)
RB30 1-234-372-11 RES, NETWORK 100 (1005X4)
RB301 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB302 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB303 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB304 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB305 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB306 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB307 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB308 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB309 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
< TERMINAL >
TB1000 1-854-001-21 TERMINAL BOARD (SPEAKER)
(SUBWOOFERS IMPEDANCE USE 4Ω R/L)
TB1001 1-854-003-21 TERMINAL BOARD
(TWEETERS/WOOFERS IMPEDANCE USE 4Ω
R/L)
< THERMISTOR >
0 TH1000 1-804-045-11 THERMISTOR
0 TH1001 1-804-045-11 THERMISTOR
0 TH1002 1-804-045-11 THERMISTOR
0 TH1003 1-804-045-11 THERMISTOR
< VIBRATOR >
X9 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768kHz)
X11 1-814-446-11 QUARTZ CRYSTAL UNIT (8MHz)
X301 1-814-023-11 QUARTS CRYSTAL UNIT (27MHz)
X460 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
X762 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288MHz)
X2000 1-814-306-11 VIBRATOR, CRYSTAL (24MHz)
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire LOADING ASSY (T).
*************************************************************
0 STR BOARD
**********
< CAPACITOR >
C3050 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C3051 1-126-791-11 ELECT 10uF 20% 35V
C3052 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3053 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3054 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3055 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3056 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C3057 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C3059 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C3060 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3061 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3062 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3064 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3065 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3066 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3067 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3068 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3069 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3070 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3071 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3072 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C3073 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
MOTHERBOARD
MS-476
STR
