17
HCD-U1BT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R554 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R555 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R556 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R557 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R558 1-216-841-11 METAL CHIP 47K 5% 1/10W
R559 1-216-837-11 METAL CHIP 22K 5% 1/10W
R560 1-216-833-11 METAL CHIP 10K 5% 1/10W
R561 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R562 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R563 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R564 1-216-821-11 METAL CHIP 1K 5% 1/10W
R567 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R568 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R569 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R570 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R571 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R572 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R573 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R574 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S500 1-571-914-21 SWITCH, KEY BOARD (Z)
S501 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S502 1-762-875-21 SWITCH, KEYBOARD (VOLUME–)
S503 1-762-875-21 SWITCH, KEYBOARD (VOLUME+)
S504 1-762-875-21 SWITCH, KEYBOARD (CD NX)
S505 1-762-875-21 SWITCH, KEYBOARD (USB NX)
S506 1-762-875-21 SWITCH, KEYBOARD (BLUTOOTH N)
S507 1-571-914-21 SWITCH, KEY BOARD (?/1)
S508 1-762-875-21 SWITCH, KEYBOARD (AUDIO IN)
S509 1-762-875-21 SWITCH, KEYBOARD (m. –TUNE)
S510 1-762-875-21 SWITCH, KEYBOARD (m)
S511 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S512 1-762-875-21 SWITCH, KEYBOARD (M)
S513 1-762-875-21 SWITCH, KEYBOARD (M> +TUNE)
S514 1-762-875-21 SWITCH, KEYBOARD (x CANCEL)
S515 1-762-875-21 SWITCH, KEYBOARD (SEARCH)
S516 1-762-875-21 SWITCH, KEYBOARD (DSGX)
< VIBRATOR >
X301 1-760-489-11 VIBRATOR, CERAMIC (5MHz)
*************************************************************
A-1186-658-A REG BOARD, COMPLETE
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-126-964-11 ELECT 10uF 20% 50V
C102 1-126-925-91 ELECT 470uF 20% 10V
C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C114 1-126-925-91 ELECT 470uF 20% 10V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C132 1-126-925-91 ELECT 470uF 20% 10V
< IC >
IC101 8-759-646-52 IC KIA7805API
IC104 8-759-071-48 IC TA7807S
IC105 6-703-546-01 IC TA7804LS
< TRANSISTOR >
Q103 8-729-024-95 TRANSISTOR 2SB1565EF
*************************************************************
SP BOARD
*********
< CAPACITOR >
C601 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C602 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C605 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C606 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
< TERMINAL >
J601 1-537-114-21 TERMINAL BOARD (SPEAKER)
*************************************************************
PANEL REG SP
