51
HCD-U1BT
•Waveforms
– BD83S Board – – USB Board –
– PANEL Board ––
1 IC201 u; (RFACO)
(CD PLAY mode)
200 mV/DIV, 500 ns/DIV
2 IC201 <z/, (XTAO)
(CD PLAY mode)
1 V/DIV, 20 ns/DIV
3 IC201 1 (LRCK)
(CD PLAY mode)
1 V/DIV, 10 µ s/DIV
4 IC201 5 (BCK)
(CD PLAY mode)
1 V/DIV, 200 ns/DIV
0.5 to 1.3 Vp-p
59.1 ns
3.3 Vp-p
22.7 µ s
3.3 Vp-p
472 ns
3.4 Vp-p
1 IC302 qg (X IN)
198 ns
2.46 Vp-p
1 V/DIV, 100 ns/DIV
1 IC8 <xxb (EXTAL)
44.6 ns
1.62 Vp-p
1 V/DIV, 10 ns/DIV
2 IC8 <zxn (TEX)
20.9 ns
1 Vp-p
500 mV/DIV, 5 ns/DIV
1 IC107 0 (XC IN)
30.6 µ s
1.5 Vp-p
500 mV/DIV, 10
µ s/DIV
2 IC107 qg (X IN)
201 ns
2.78 Vp-p
1 V/DIV, 100 ns/DIV
1 IC701 0 (LRCK)
22.8 µ s
3.2 Vp-p
1 V/DIV, 10
µ s/DIV
2 IC701 qa (BCK)
324 ns
3.6 Vp-p
1 V/DIV, 100 ns/DIV
82 ns
4 Vp-p
1 V/DIV, 50 ns/DIV
3 IC703 8 (Q2)
20.4 ns
3.9 Vp-p
1 V/DIV, 10 ns/DIV
4 IC705 rk (XFSOIN)
– SMASTER Board ––
– MAIN Board –
