Sony HCD-U1BT - Page 52

52
HCD-U1BT
• IC Block Diagrams
IC402 BA5947FM-E2
– BD83S Board –
1
LEVEL SHIFT
MUTING
D
15
16
+
–
+
–
DD
17
18
D
19
20
VREF
21
22
23
24
25
26
27
28
PREVCC OPOUT OUTVREF CH4CAPA CH4IN CH3FIN CH3RIN GND MUTE POWVCC CH3OUTF CH3OUTR CH4OUTF CH4OUTR
OPIN–
2
OPIN+
INTERFACE
14
13
D
12
11
D
10
9
8
7
6
CH2FIN
CH2RIN
GND
5
4
CH1FIN
CH1RIN
VREFIN
POWVCC
CH2OUTR
CH2OUTF
CH1OUTR
CH1OUTF
INTERFACE
D D
3
SW
INTERFACE
IC203 BH18LB1WG-TR
1VIN
2GND
3
STBY
4
NC
5
VOUT
VOLTAGE
REFERENCE
THERMAL
PROTECTION
OVER CURRENT
PROTECTION
CONTROL
BLOCK
