85
HCD-U1BT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
0 D1 8-719-077-77 DIODE D3SB60F3
0 D2 8-719-081-58 DIODE S2V60-TA (US, CND)
0 D3 8-719-081-58 DIODE S2V60-TA (US, CND)
0 D11 8-719-979-64 DIODE UF4005/23
0 D14 6-500-567-31 DIODE 10ERB20-TB3
0 D15 6-501-178-01 DIODE UDZW-TE17-15B
0 D16 6-501-178-01 DIODE UDZW-TE17-15B
0 D17 8-719-060-48 DIODE RB751V-40TE-17
D31 8-719-510-09 DIODE D10SC6M
D32 6-501-518-01 DIODE RB085T-90
D33 8-719-110-49 DIODE RD18ESB2
0 D602 8-719-073-23 DIODE ST02D-200TA
0 D603 6-500-567-31 DIODE 10ERB20-TB3
D604 6-500-567-31 DIODE 10ERB20-TB3
D652 6-501-179-01 DIODE UDZW-TE17-16B
< FUSE >
0 F1 1-576-232-51 FUSE (T5AL/250V)
< FERRITE BEAD >
0 FB11 1-410-397-21 FERRITE 1.1uH
< IC >
0 IC11 6-707-749-01 IC CXD9841P
IC12 8-759-231-58 IC TA7812S
0 IC601 6-708-726-01 IC MIP2F20MS1SO
IC650 6-705-280-01 IC FAN431AZXA
< JUMPER RESISTOR >
JR30 1-216-864-11 SHORT CHIP 0
JR31 1-216-864-11 SHORT CHIP 0
JR32 1-216-864-11 SHORT CHIP 0
< COIL >
L602 1-412-525-31 INDUCTOR 10uH
< PHOTO INTERRUPTER >
0 PH11 6-600-438-01 IC TLP421F (D4-GR)
0 PH601 6-600-438-01 IC TLP421F (D4-GR)
0 PH602 6-600-438-01 IC TLP421F (D4-GR)
< TRANSISTOR >
0 Q11 6-551-319-01 TRANSISTOR 2SK3563 (LB2SONY)
0 Q12 6-551-319-01 TRANSISTOR 2SK3563 (LB2SONY)
0 Q601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q650 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q651 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q652 8-729-600-22 TRANSISTOR 2SA1235-F
< RESISTOR >
0 R1 1-219-512-11 METAL 2.2M 5% 1/2W
(US, CND)
0 R2 1-219-512-11 METAL 2.2M 5% 1/2W
0 R10 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
0R11 1-216-797-11 METAL CHIP 10 5% 1/10W
(US, CND)
0R11 1-216-864-11 SHORT CHIP 0 (AEP, UK, KR)
0R12 1-245-502-31 METAL 4.7M 2% 1/4W
0R13 1-245-502-31 METAL 4.7M 2% 1/4W
0R14 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
0R15 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
0R16 1-218-823-11 METAL CHIP 100 0.5% 1/10W
0R17 1-218-823-11 METAL CHIP 100 0.5% 1/10W
0R18 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R20 1-216-833-11 METAL CHIP 10K 5% 1/10W
0R22 1-249-417-11 CARBON 1K 5% 1/4W
0R23 1-217-568-71 METAL 0.22 5% 2W
0R24 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R25 1-247-694-11 CARBON 33 5% 1/4W
0R27 1-216-797-11 METAL CHIP 10 5% 1/10W
0R29 1-216-797-11 METAL CHIP 10 5% 1/10W
R32 1-216-821-11 METAL CHIP 1K 5% 1/10W
R33 1-216-817-11 METAL CHIP 470 5% 1/10W
R41 1-216-845-11 METAL CHIP 100K 5% 1/10W
0R603 1-216-853-11 METAL CHIP 470K 5% 1/10W
0R604 1-249-401-11 CARBON 47 5% 1/4W
0R605 1-216-835-11 METAL CHIP 15K 5% 1/10W
0R606 1-249-381-11 CARBON 1 5% 1/4W
0R607 1-216-864-11 SHORT CHIP 0
0R608 1-216-821-11 METAL CHIP 1K 5% 1/10W
0R609 1-218-899-11 METAL CHIP 150K 0.5% 1/16W
0R610 1-218-907-11 METAL CHIP 330K 0.5% 1/10W
R651 1-216-821-11 METAL CHIP 1K 5% 1/10W
R652 1-216-817-11 METAL CHIP 470 5% 1/10W
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R654 1-216-841-11 METAL CHIP 47K 5% 1/10W
R655 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R656 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R657 1-216-805-11 METAL CHIP 47 5% 1/10W
R658 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R659 1-216-821-11 METAL CHIP 1K 5% 1/10W
R660 1-216-821-11 METAL CHIP 1K 5% 1/10W
R661 1-216-833-11 METAL CHIP 10K 5% 1/10W
R662 1-216-833-11 METAL CHIP 10K 5% 1/10W
R663 1-216-817-11 METAL CHIP 470 5% 1/10W
< TRANSFORMER >
0T1 1-445-048-11 TRANSFORMER, LINE FILTER (AEP, UK, KR)
0T1 1-457-326-11 COIL, LINE FILTER (US, CND)
0T31 1-445-053-11 TRANSFORMER, CONVERTER
0T603 1-443-942-11 TRANSFORMER, DC-DC CONVERTER
< TERMINAL >
TB1 1-695-915-11 TAB (CONTACT)
< THERMISTOR >
0TH1 1-802-073-11 THERMISTOR, NTC (AEP, UK, KR)
0TH1 1-802-074-11 THERMISTOR, NTC (US, CND)
0TH2 1-802-074-11 THERMISTOR, NTC (US, CND)
< TERMINAL >
* TK1 1-537-738-21 TERMINAL, EARTH
* TK3 1-537-738-21 TERMINAL, EARTH
SW POWER
Ver. 1.3
