86
HCD-U1BT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< VARIABLE RESISTOR >
0VR001 1-805-481-21 VARISTOR (US, CND)
0VR001 1-805-482-11 VARISTOR (AEP, UK, KR)
*************************************************************
✩ X-2149-040-1 USB BOARD, COMPLETE
********************
< CAPACITOR >
C1 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C3 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C4 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C8 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C9 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C10 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C11 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C12 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C13 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C14 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C15 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C16 1-124-779-00 ELECT CHIP 10uF 20% 16V
C17 1-124-779-00 ELECT CHIP 10uF 20% 16V
C18 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C19 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C20 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C21 1-124-779-00 ELECT CHIP 10uF 20% 16V
C22 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C23 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C24 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C25 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C26 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C28 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C29 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C31 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C32 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C33 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C34 1-164-843-11 CERAMIC CHIP 3PF 0.25PF 50V
C35 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C36 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C38 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C39 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C41 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C42 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C43 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C44 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C47 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C48 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C49 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C51 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C52 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C53 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C54 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C55 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C56 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C57 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C58 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C59 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C60 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C61 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C62 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C63 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C64 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C65 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C66 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C67 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN1 1-793-580-11 CONNECTOR, FFC (LIF (NON-Z1F)) 15P
CN2 1-794-548-21 CONNECTOR, USB (A) ( )
< DIODE >
D1 6-500-335-01 DIODE MC2838-T112-1
D2 6-501-193-01 DIODE 1SS355WTE-17
D3 6-500-848-01 DIODE MC2840-T112-1
D4 6-500-848-01 DIODE MC2840-T112-1
D5 6-500-848-01 DIODE MC2840-T112-1
< JUMPER RESISTOR >
FB1 1-216-864-11 SHORT CHIP 0
FB2 1-216-864-11 SHORT CHIP 0
FB3 1-216-864-11 SHORT CHIP 0
FB4 1-216-295-91 SHORT CHIP 0
FB5 1-216-295-91 SHORT CHIP 0
FB6 1-216-864-11 SHORT CHIP 0
FB7 1-216-864-11 SHORT CHIP 0
FB8 1-216-295-91 SHORT CHIP 0
FB9 1-216-864-11 SHORT CHIP 0
FB10 1-216-295-91 SHORT CHIP 0
< IC >
IC1 6-709-821-01 IC R5520H001A-T1-FB
IC2 6-709-822-01 IC R1180N121B-TR-FA
IC3 6-709-823-01 IC XC6219B332PR
IC4 6-709-822-01 IC R1180N121B-TR-FA
✩ IC6 (Not supplied) IC S29AL016D70TFI020
IC7 6-704-832-01 IC IS61LV6416-10TLT
IC8 8-753-249-16 IC CXD5080GG
< TRANSISTOR >
Q1 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q2 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q4 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q5 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q8 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q9 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q10 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1 1-218-965-11 RES-CHIP 10K 5% 1/16W
R2 1-218-965-11 RES-CHIP 10K 5% 1/16W
R3 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4 1-218-965-11 RES-CHIP 10K 5% 1/16W
R5 1-218-941-81 RES-CHIP 100 5% 1/16W
USB
✩ New part of EEP ROM (IC6) on the USB board cannot be used.
Therefore, if the mounted USB board (X-2149-040-1) is replaced,
exchange new EEP ROM (IC6) with that used before the
replacement.
SW POWER
Ver. 1.3
