Sony HCD-V5500 - 8 Electrical Parts List

Note:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 76 —
SECTION 8
ELECTRICAL PARTS LIST
* A-2007-435-AAUDIO BOARD, COMPLETE
**********************
< CAPACITOR >
C301 1-162-289-31CERAMIC 390PF 10% 50V
C302 1-126-968-11ELECT 100uF 20% 6.3V
C303 1-162-282-31CERAMIC 100PF 10% 50V
C304 1-130-483-00MYLAR 0.01uF 5% 50V
C305 1-107-715-11ELECT 22uF 20% 16V
C311 1-162-289-31CERAMIC 390PF 10% 50V
C313 1-162-282-31CERAMIC 100PF 10% 50V
C314 1-130-487-00MYLAR 0.022uF 5% 50V
C315 1-126-233-11ELECT 22uF 20% 50V
C331 1-137-427-11FILM 120PF 5% 50V
C332 1-162-288-31CERAMIC 330PF 10% 50V
C333 1-162-209-31CERAMIC 27PF 5% 50V
C401 1-162-289-31CERAMIC 390PF 10% 50V
C402 1-126-968-11ELECT 100uF 20% 6.3V
C403 1-162-282-31CERAMIC 100PF 10% 50V
C404 1-130-483-00MYLAR 0.01uF 5% 50V
C405 1-107-715-11ELECT 22uF 20% 16V
C411 1-162-289-31CERAMIC 390PF 10% 50V
C413 1-162-282-31CERAMIC 100PF 10% 50V
C414 1-130-487-00MYLAR 0.022uF 5% 50V
C415 1-126-233-11ELECT 22uF 20% 50V
C431 1-137-427-11FILM 120PF 5% 50V
C432 1-162-288-31CERAMIC 330PF 10% 50V
C433 1-162-209-31CERAMIC 27PF 5% 50V
C601 1-104-396-11ELECT 10uF 20% 16V
C602 1-104-396-11ELECT 10uF 20% 16V
C611 1-124-907-11ELECT 10uF 20% 50V
C612 1-124-907-11ELECT 10uF 20% 50V
C621 1-137-150-11FILM 0.01uF 5% 100V
C622 1-126-961-11ELECT 2.2uF 20% 50V
C623 1-136-155-00FILM 0.015uF 5% 50V
C624 1-130-481-00MYLAR 0.0068uF5% 50V
C625 1-130-481-00MYLAR 0.0068uF5% 50V
C627 1-124-903-11ELECT 1uF 20% 50V
C628 1-136-153-00FILM 0.01uF 5% 50V
C642 1-104-664-11ELECT 47uF 20% 16V
C651 1-161-494-00CERAMIC 0.022uF 25V
< CONNECTOR >
CN601 1-695-382-31PIN, CONNECTOR (PC BOARD) 21P
CN602 1-564-718-11PIN, CONNECTOR (SMALL TYPE) 2P
* CN651 1-564-521-11PLUG, CONNECTOR 6P
< IC >
IC601 8-759-111-44IC uPC4570C-1
IC601 8-759-710-59IC NJM4580D-D
IC602 8-759-143-54IC uPC1330HA
IC611 8-759-111-44IC uPC4570C-1
IC611 8-759-710-59IC NJM4580D-D
< COIL >
L331 1-410-780-11INDUCTOR 27mH
L431 1-410-780-11INDUCTOR 27mH
< TRANSISTOR >
Q621 8-729-142-46TRANSISTOR 2SC2001-LK
Q622 8-729-142-46TRANSISTOR 2SC2001-LK
Q623 8-729-030-18TRANSISTOR 2SD2525
Q651 8-729-900-65TRANSISTOR DTA144ES
< RESISTOR >
R301 1-247-881-00CARBON 120K 5% 1/4W
R302 1-249-409-11CARBON 220 5% 1/4W F
R303 1-249-433-11CARBON 22K 5% 1/4W
R304 1-247-889-00CARBON 270K 5% 1/4W
R305 1-247-858-11CARBON 13K 5% 1/4W
R311 1-247-881-00CARBON 120K 5% 1/4W
R312 1-247-807-31CARBON 100 5% 1/4W
R314 1-247-882-11CARBON 130K 5% 1/4W
R315 1-247-850-11CARBON 6.2K 5% 1/4W
R331 1-249-430-11CARBON 12K 5% 1/4W
R401 1-247-881-00CARBON 120K 5% 1/4W
R402 1-249-409-11CARBON 220 5% 1/4W F
R403 1-249-433-11CARBON 22K 5% 1/4W
R404 1-247-889-00CARBON 270K 5% 1/4W
R405 1-247-858-11CARBON 13K 5% 1/4W
R411 1-247-881-00CARBON 120K 5% 1/4W
R412 1-247-807-31CARBON 100 5% 1/4W
R414 1-247-882-11CARBON 130K 5% 1/4W
R415 1-247-850-11CARBON 6.2K 5% 1/4W
R431 1-249-430-11CARBON 12K 5% 1/4W
R601 1-249-409-11CARBON 220 5% 1/4W F
R602 1-249-409-11CARBON 220 5% 1/4W F
R608 1-249-409-11CARBON 220 5% 1/4W F
R609 1-249-433-11CARBON 22K 5% 1/4W
R611 1-249-409-11CARBON 220 5% 1/4W F
R612 1-249-409-11CARBON 220 5% 1/4W F
! R621 1-212-851-00FUSIBLE 5.6 5% 1/4W F
! R622 1-212-851-00FUSIBLE 5.6 5% 1/4W F
R623 1-249-432-11CARBON 18K 5% 1/4W
R624 1-249-432-11CARBON 18K 5% 1/4W
AUDIO
• Abbreviation
MY: Malaysia CH : Chinese
SP : Singapore TH : Thai
HK : Hong Kong IA : Indonesian
KR : Korean
