Ref. No.Part No. Description Remarks Ref. No. Part No. Description Remarks
— 77 —
R625 1-249-429-11CARBON 10K 5% 1/4W
R651 1-247-856-00CARBON 11K 5% 1/4W
R652 1-247-856-00CARBON 11K 5% 1/4W
R653 1-249-441-11CARBON 100K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-238-598-11RES, ADJ, CARBON 2.2K
RV311 1-238-598-11RES, ADJ, CARBON 2.2K
RV341 1-238-551-11RES, ADJ, CARBON 220K
RV401 1-238-598-11RES, ADJ, CARBON 2.2K
RV411 1-238-598-11RES, ADJ, CARBON 2.2K
RV441 1-238-551-11RES, ADJ, CARBON 220K
RV651 1-238-599-11RES, ADJ, CARBON 4.7K
RV652 1-238-599-11RES, ADJ, CARBON 4.7K
< TRANSFORMER >
T621 1-423-980-11TRANSFORMER, BIAS OSCILLATION
************************************************************
* A-4673-557-ABD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-005-11CERAMIC CHIP 470PF 10% 50V
C102 1-163-038-91CERAMIC CHIP 0.1uF 25V
C103 1-163-005-11CERAMIC CHIP 470PF 10% 50V
C105 1-104-913-11TANTAL. CHIP 10uF 20% 16V
C106 1-164-346-11CERAMIC CHIP 1uF 16V
C107 1-164-346-11CERAMIC CHIP 1uF 16V
C108 1-163-035-00CERAMIC CHIP 0.047uF 50V
C109 1-163-145-00CERAMIC CHIP 0.0015uF5% 50V
C110 1-163-017-00CERAMIC CHIP 0.0047uF5% 50V
C111 1-163-251-11CERAMIC CHIP 100PF 5% 50V
C112 1-163-038-91CERAMIC CHIP 0.1uF 25V
C113 1-163-038-91CERAMIC CHIP 0.1uF 25V
C115 1-126-607-11ELECT CHIP 47uF 20% 4V
C116 1-126-607-11ELECT CHIP 47uF 20% 4V
C117 1-126-209-11ELECT 100uF 20% 4V
C118 1-163-275-11CERAMIC CHIP 0.001uF 5% 50V
C119 1-163-235-11CERAMIC CHIP 22PF 5% 50V
C123 1-164-232-11CERAMIC CHIP 0.01uF 50V
C124 1-164-005-11CERAMIC CHIP 0.47uF 25V
C125 1-104-913-11TANTAL. CHIP 10uF 20% 16V
C140 1-163-038-91CERAMIC CHIP 0.1uF 25V
C141 1-163-038-91CERAMIC CHIP 0.1uF 25V
C151 1-163-237-11CERAMIC CHIP 27PF 5% 50V
C153 1-163-038-91CERAMIC CHIP 0.1uF 25V
C154 1-164-336-11CERAMIC CHIP 0.33uF 25V
C156 1-163-237-11CERAMIC CHIP 27PF 5% 50V
C157 1-163-145-00CERAMIC CHIP 0.0015uF5% 50V
C159 1-163-019-00CERAMIC CHIP 0.0068uF10% 50V
C161 1-163-038-91CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-774-115-11CONNECTOR, (FFC/FPC) 29P
CN102 1-770-014-11CONNECTOR, FFC/FPC 16P
< IC >
IC101 8-752-369-78IC CXD2545Q
IC102 8-759-176-09IC BA6392FP
IC103 8-752-072-45IC CXA1821M-T6
< TRANSISTOR >
Q101 8-729-010-08TRANSISTOR MSB710-R
< RESISTOR >
R101 1-216-077-00METAL CHIP 15K 5% 1/10W
R102 1-216-097-91METAL GLAZE 100K 5% 1/10W
R103 1-216-077-00METAL CHIP 15K 5% 1/10W
R104 1-216-085-00METAL CHIP 33K 5% 1/10W
R105 1-216-097-91METAL GLAZE 100K 5% 1/10W
R106 1-216-061-00METAL CHIP 3.3K 5% 1/10W
R107 1-216-061-00METAL CHIP 3.3K 5% 1/10W
R108 1-216-073-00METAL CHIP 10K 5% 1/10W
R109 1-216-121-91METAL GLAZE 1M 5% 1/10W
R110 1-216-025-91METAL GLAZE 100 5% 1/10W
R112 1-216-049-91METAL GLAZE 1K 5% 1/10W
R123 1-216-073-00METAL CHIP 10K 5% 1/10W
R124 1-216-097-91METAL GLAZE 100K 5% 1/10W
R125 1-216-033-00METAL CHIP 220 5% 1/10W
R126 1-216-033-00METAL CHIP 220 5% 1/10W
R127 1-216-033-00METAL CHIP 220 5% 1/10W
R131 1-216-037-00METAL CHIP 330 5% 1/10W
R132 1-216-073-00METAL CHIP 10K 5% 1/10W
R134 1-216-049-91METAL GLAZE 1K 5% 1/10W
R135 1-216-295-91CONDUCTOR, CHIP (2012)
R136 1-216-295-91CONDUCTOR, CHIP (2012)
R137 1-216-295-91CONDUCTOR, CHIP (2012)
R138 1-216-295-91CONDUCTOR, CHIP (2012)
R141 1-216-089-91METAL GLAZE 47K 5% 1/10W
R142 1-216-081-00METAL CHIP 22K 5% 1/10W
R143 1-216-103-00METAL CHIP 180K 5% 1/10W
R144 1-216-103-00METAL CHIP 180K 5% 1/10W
R146 1-216-073-00METAL CHIP 10K 5% 1/10W
R147 1-216-067-00METAL CHIP 5.6K 5% 1/10W
R148 1-216-001-00METAL CHIP 10 5% 1/10W
R149 1-216-003-11METAL GLAZE 12 5% 1/10W
R158 1-216-109-00METAL CHIP 330K 5% 1/10W
R159 1-216-101-00METAL CHIP 150K 5% 1/10W
R160 1-216-295-91CONDUCTOR, CHIP (2012)
R161 1-216-308-00METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00METAL CHIP 150K 5% 1/10W
< SWITCH >
S101 1-572-085-11SWITCH, LEAF (LIMIT)
************************************************************
* A-4403-280-ACD PANEL BOARD, COMPLETE
*************************
< CONNECTOR >
CNL102 1-568-860-21SOCKET, CONNECTOR 17P
< DIODE >
D211 8-719-812-44DIODE TLO124
D212 8-719-812-44DIODE TLO124
D213 8-719-033-06DIODE SEL5920A
D214 8-719-033-06DIODE SEL5920A
D215 8-719-032-86DIODE SEL5420E
AUDIO BD CD PANEL
To Next Page
